Parker AC30 series User Manual

D-130 Parameter Reference
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0131
Write Mapping[10]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00789
0132
Write Mapping[11]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00791
0133
Write Mapping[12]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00793
0134
Write Mapping[13]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00795
0135
Write Mapping[14]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00797
0136
Write Mapping[15]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00799
0137
Write Mapping[16]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00801
0138
Write Mapping[17]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00803
0139
Write Mapping[18]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00805
0140
Write Mapping[19]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00807
0141
Write Mapping[20]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00809
0142
Write Mapping[21]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00811
0143
Write Mapping[22]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00813
0144
Write Mapping[23]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00815
0145
Write Mapping[24]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00817
0146
Write Mapping[25]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00819
0147
Write Mapping[26]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00821
0148
Write Mapping[27]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00823
0149
Write Mapping[28]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00825
0150
Write Mapping[29]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00827
0151
Write Mapping[30]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00829
0152
Write Mapping[31]
Same as PNO 120
UINT
0000
0000 to 2149
CONFIG
TECHNICIAN
00831
0185
Comms Event Code
Parameters::Option Comms::Event
BYTE
00
ALWAYS
ENGINEER
2
00897
0186
Comms Event Active
Monitor::Communications::Option
Parameters::Option Comms::Event
BOOL NEVER OPERATOR
00899
0187
Comms Event Set
Parameters::Option Comms::Event
BOOL
FALSE
ALWAYS
ENGINEER
2
00901
0188
Comms Event Clear
Parameters::Option Comms::Event
BOOL
FALSE
ALWAYS
ENGINEER
2
00903
0189
Option MAC Address
Monitor::Communications::Option
Parameters::Option Comms::Option Ethernet
STRING[18] NEVER TECHNICIAN
00905
0195
Option IP Address Same as PNO 189
DWORD
(IP addr)
NEVER OPERATOR
00917
0196
Option Subnet Mask Same as PNO 189
DWORD
(IP addr)
NEVER OPERATOR
00919
0197
Option Gateway Same as PNO 189
DWORD
(IP addr)
NEVER OPERATOR
00921
0198
Option DHCP Enabled
Same as PNO 189
BOOL
NEVER
TECHNICIAN
00923
0199
Address Assignment
Setup::Communications::Option
Parameters::Option Comms::Option Ethernet
USINT
(enum)
0
0:FIXED
1:EXTERNAL
2:DHCP
CONFIG TECHNICIAN
00925
0200
Fixed IP Address Same as PNO 199
DWORD
(IP addr)
000.000.000.000 CONFIG TECHNICIAN 7
00927
0201
Fixed Subnet Mask Same as PNO 199
DWORD
(IP addr)
000.000.000.000 CONFIG TECHNICIAN 7
00929
0202
Fixed Gateway Address Same as PNO 199
DWORD
(IP addr)
000.000.000.000 CONFIG TECHNICIAN 7
00931
0203
Option Web Enable
Same as PNO 199
BOOL
TRUE
CONFIG
TECHNICIAN
00933
0204
Web Parameters Enable
Same as PNO 199
BOOL
TRUE
CONFIG
TECHNICIAN
00935
0205
Option FTP Enable
Same as PNO 199
BOOL
TRUE
CONFIG
ENGINEER
00937
0206
Option FTP Admin Mode
Same as PNO 199
BOOL
TRUE
CONFIG
ENGINEER
00939
0207
IPConfig Enable
Same as PNO 199
BOOL
TRUE
CONFIG
ENGINEER
00941
0208
BACnet IP State
Monitor::Communications::Option
Parameters::Option Comms::BACnet IP
USINT
(enum)
Same as PNO 46 NEVER OPERATOR
00943
0209
BACnet IP Device ID
Setup::Communications::Option
Parameters::Option Comms::BACnet IP
UDINT 0 0 to 4194302 CONFIG TECHNICIAN 7
00945
0210
BACnet IP Timeout
Same as PNO 209
TIME
3.000
0.000 to 65.000
s
CONFIG
TECHNICIAN
00947
