Parker AC30 series User Manual

Parameter Reference D-141
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0697
Enable 1 - 32 Parameters::Trips::Trips Status
DWORD
(bitfield)
0000FF7F
5:06 CURRENT LIMIT
6:07 MOTOR STALL
7:08 INVERSE TIME
8:09 MOTOR I2T
9:10 LOW SPEED I
11:12 INTERNAL
OVERTEMP
12:13 MOTOR OVERTEMP
13:14 EXTERNAL TRIP
14:15 BRAKE SHORT CCT
15:16 BRAKE RESISTOR
16:17 BRAKE SWITCH
17:18 LOCAL CONTROL
18:19 COMMS BREAK
19:20 LINE CONTACTOR
20:21 PHASE FAIL
21:22 VDC RIPPLE
22:23 BASE MODBUS
BREAK
23:24 24 V OVERLOAD
24:25 PMAC SPEED
ERROR
25:26 OVERSPEED
28:29 INTERNAL FAN FAIL
29:30 CURRENT SENSOR
30:31 POWER LOSS STOP
ALWAYS TECHNICIAN
01921
0703
Enable 1 - 32.06 CURRENT LIMIT
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01933
0704
Enable 1 - 32.07 MOTOR STALL
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01935
0705
Enable 1 - 32.08 INVERSE TIME
Parameters::Trips::Trips Status
BOOL
FALSE
ALWAYS
TECHNICIAN
01937
0706
Enable 1 - 32.09 MOTOR I2T
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01939
0707
Enable 1 - 32.10 LOW SPEED I
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01941
0709
Enable 1 - 32.12 INTERNAL OVERTEMP
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01945
0710
Enable 1 - 32.13 MOTOR OVERTEMP
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01947
0711
Enable 1 - 32.14 EXTERNAL TRIP
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01949
0712
Enable 1 - 32.15 BRAKE SHORT CCT
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01951
0713
Enable 1 - 32.16 BRAKE RESISTOR
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01953
0714
Enable 1 - 32.17 BRAKE SWITCH
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01955
0715
Enable 1 - 32.18 LOCAL CONTROL
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01957
0716
Enable 1 - 32.19 COMMS BREAK
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01959
0717
Enable 1 - 32.20 LINE CONTACTOR
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01961
0718
Enable 1 - 32.21 PHASE FAIL
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01963
0719
Enable 1 - 32.22 VDC RIPPLE
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01965
0720
Enable 1 - 32.23 BASE MODBUS BREAK
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01967
0721
Enable 1 - 32.24 24 V OVERLOAD
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01969
0722
Enable 1 - 32.25 PMAC SPEED ERROR
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01971
0723
Enable 1 - 32.26 OVERSPEED
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01973
0726
Enable 1 - 32.29 INTERNAL FAN FAIL
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01979
0727
Enable 1 - 32.30 CURRENT SENSOR
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01981
0728
Enable 1 - 32.31 POWER LOSS STOP
Parameters::Trips::Trips Status
BOOL
TRUE
ALWAYS
TECHNICIAN
01983
