Parker AC30 series User Manual

D-142 Parameter Reference
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0763
Active 1 - 32
Monitor::Trips
Parameters::Trips::Trips Status
DWORD
(bitfield)
0:01 OVER VOLTAGE
1:02 UNDER VOLTAGE
2:03 OVER CURRENT
3:04 STACK FAULT
4:05 STACK OVER
CURRENT
5:06 CURRENT LIMIT
6:07 MOTOR STALL
7:08 INVERSE TIME
8:09 MOTOR I2T
9:10 LOW SPEED I
10:11 HEATSINK
OVERTEMP
11:12 INTERNAL
OVERTEMP
12:13 MOTOR OVERTEMP
13:14 EXTERNAL TRIP
14:15 BRAKE SHORT CCT
15:16 BRAKE RESISTOR
16:17 BRAKE SWITCH
17:18 LOCAL CONTROL
18:19 COMMS BREAK
19:20 LINE CONTACTOR
20:21 PHASE FAIL
21:22 VDC RIPPLE
22:23 BASE MODBUS
BREAK
23:24 24 V OVERLOAD
24:25 PMAC SPEED
ERROR
25:26 OVERSPEED
26:27 STO ACTIVE
27:28 FEEDBACK MISSING
28:29 INTERNAL FAN FAIL
29:30 CURRENT SENSOR
30:31 POWER LOSS STOP
NEVER OPERATOR
02053
0764
Active 1 - 32.01 OVER VOLTAGE
Same as PNO 763
BOOL
NEVER
OPERATOR
02055
0765
Active 1 - 32.02 UNDER VOLTAGE
Same as PNO 763
BOOL
NEVER
OPERATOR
02057
0766
Active 1 - 32.03 OVER CURRENT
Same as PNO 763
BOOL
NEVER
OPERATOR
02059
0767
Active 1 - 32.04 STACK FAULT
Same as PNO 763
BOOL
NEVER
OPERATOR
02061
0768
Active 1 - 32.05 STACK OVER CURRENT
Same as PNO 763
BOOL
NEVER
OPERATOR
02063
0769
Active 1 - 32.06 CURRENT LIMIT
Same as PNO 763
BOOL
NEVER
OPERATOR
02065
0770
Active 1 - 32.07 MOTOR STALL
Same as PNO 763
BOOL
NEVER
OPERATOR
02067
0771
Active 1 - 32.08 INVERSE TIME
Same as PNO 763
BOOL
NEVER
OPERATOR
02069
0772
Active 1 - 32.09 MOTOR I2T
Same as PNO 763
BOOL
NEVER
OPERATOR
02071
0773
Active 1 - 32.10 LOW SPEED I
Same as PNO 763
BOOL
NEVER
OPERATOR
02073
0774
Active 1 - 32.11 HEATSINK OVERTEMP
Same as PNO 763
BOOL
NEVER
OPERATOR
02075
0775
Active 1 - 32.12 INTERNAL OVERTEMP
Same as PNO 763
BOOL
NEVER
OPERATOR
02077
0776
Active 1 - 32.13 MOTOR OVERTEMP
Same as PNO 763
BOOL
NEVER
OPERATOR
02079
0777
Active 1 - 32.14 EXTERNAL TRIP
Same as PNO 763
BOOL
NEVER
OPERATOR
02081
0778
Active 1 - 32.15 BRAKE SHORT CCT
Same as PNO 763
BOOL
NEVER
OPERATOR
02083
0779
Active 1 - 32.16 BRAKE RESISTOR
Same as PNO 763
BOOL
NEVER
OPERATOR
02085
0780
Active 1 - 32.17 BRAKE SWITCH
Same as PNO 763
BOOL
NEVER
OPERATOR
02087
0781
Active 1 - 32.18 LOCAL CONTROL
Same as PNO 763
BOOL
NEVER
OPERATOR
02089
0782
Active 1 - 32.19 COMMS BREAK
Same as PNO 763
BOOL
NEVER
OPERATOR
02091
0783
Active 1 - 32.20 LINE CONTACTOR
Same as PNO 763
BOOL
NEVER
OPERATOR
02093
0784
Active 1 - 32.21 PHASE FAIL
Same as PNO 763
BOOL
NEVER
OPERATOR
02095
