Parker AC30 series User Manual

D-146 Parameter Reference
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0968
Warranty Trips
Parameters::Trips::Trips History
ARRAY[0..2]
NEVER
ENGINEER
02463
0969
Warranty Trips[0] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER ENGINEER 1
02465
0970
Warranty Trips[1] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER ENGINEER 1
02467
0971
Warranty Trips[2] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER ENGINEER 1
02469
0972
Warranty Trip Time
Parameters::Trips::Trips History
ARRAY[0..2]
NEVER
ENGINEER
02471
0973
Warranty Trip Time[0]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
02473
0974
Warranty Trip Time[1]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
02475
0975
Warranty Trip Time[2]
Parameters::Trips::Trips History
UDINT
0 to Max
s
NEVER
ENGINEER
1
02477
0977
Control Module Serial
Parameters::Device Manager::Drive info
STRING[15]
NEVER
OPERATOR
02481
0982
Startup Page
Setup::Environment
Parameters::Keypad::Graphical Keypad
USINT
(enum)
0
0:DEFAULT
1:CONTROL SCREEN
2:FAVOURITES
3:MONITOR
ALWAYS TECHNICIAN
02491
0983
Display Timeout
Same as PNO 982
TIME
0.000
0.000 to 86400.000
s
ALWAYS
TECHNICIAN
02493
0987
Power Stack Required Parameters::Device Manager::Drive info
USINT
(enum)
0 Same as PNO 543 CONFIG ENGINEER 6
02501
0988
Target State Parameters::Device Manager::Device State
USINT
(enum)
3
3:PREOPERATIONAL
7:OPERATIONAL
STOPPED OPERATOR 2
02503
0989
Actual State Parameters::Device Manager::Device State
USINT
(enum)
0:INITIALISING
1:INITIALISED
2:PREPARING PREOP
3:PREOPERATIONAL
4:PREPARING OP
5:FAILED TO READY
6:READY FOR OP
7:OPERATIONAL
8:FAULTED
9:FATAL ERROR
RECOVER
NEVER OPERATOR
02505
0990
Application FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02507
0991
Base IO FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02509
0992
Basic Drive FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02511
0993
Ethernet FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02513
0994
Keypad FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02515
0995
Comms Option FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02517
0996
IO Option FE State Parameters::Device Manager::Device State
USINT
(enum)
Same as PNO 989 NEVER OPERATOR
02519
0997
Config Fault Area Parameters::Device Manager::Device State
USINT
(enum)
0:NONE
1:POWER STACK
2:OPTION IO
3:OPTION COMMS
4:APPLICATION
5:MOTOR CONTROL
6:KEYPAD
7:BASE COMMS
8:BASE IO
9:FEEDBACK MISSING
NEVER OPERATOR
02521
