Parker AC30 series User Manual

Parameter Reference D-145
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0916
VDC Ripple Sample
Parameters::Trips::VDC Ripple
TIME
0.009
0.001 to 0.100
s
ALWAYS
ENGINEER
02359
0917
VDC Ripple Level
Parameters::Trips::VDC Ripple
REAL
x.
0 to 500
V
NEVER
ENGINEER
02361
0918
Filtered VDC Ripple
Parameters::Trips::VDC Ripple
REAL
x.
0 to 500
V
NEVER
ENGINEER
02363
0919
Ethernet State
Monitor::Communications::Base Ethernet
Parameters::Base Comms::Ethernet
USINT
(enum)
0:INITIALISING
1:NO LINK
2:RESOLVING IP
3:RESOLVING DHCP
4:RESOLVING AUTO
5:RESOLVED IP
6:STOPPING DHCP
7:DUPLICATE IP
8:FAULT
NEVER OPERATOR
02365
0920
MAC Address
Same as PNO 919
STRING[17]
NEVER
OPERATOR
02367
0926
IP Address Same as PNO 919
DWORD
(IP addr)
NEVER OPERATOR
02379
0927
Subnet Mask Same as PNO 919
DWORD
(IP addr)
NEVER OPERATOR
02381
0928
Gateway Address Same as PNO 919
DWORD
(IP addr)
NEVER OPERATOR
02383
0929
DHCP
Setup::Communications::Base Ethernet
Parameters::Base Comms::Ethernet
BOOL TRUE ALWAYS TECHNICIAN
02385
0930
Auto IP
Same as PNO 929
BOOL
TRUE
ALWAYS
TECHNICIAN
02387
0931
Last Auto IP Address Parameters::Base Comms::Ethernet
DWORD
(IP addr)
NEVER ENGINEER 3
02389
0932
DHCP To Auto IP
Parameters::Base Comms::Ethernet
TIME
45.000
30.000 to 300.000
s
ALWAYS
TECHNICIAN
02391
0933
User IP Address Same as PNO 929
DWORD
(IP addr)
000.000.000.000 ALWAYS TECHNICIAN 7
02393
0934
User Subnet Mask Same as PNO 929
DWORD
(IP addr)
000.000.000.000 ALWAYS TECHNICIAN 7
02395
0935
User Gateway Address Same as PNO 929
DWORD
(IP addr)
000.000.000.000 ALWAYS TECHNICIAN 7
02397
0936
Lock
Parameters::Base Comms::Ethernet
BOOL
FALSE
ALWAYS
ENGINEER
02399
0937
Ethernet Diagnostic
Parameters::Base Comms::Ethernet
DWORD
NEVER
ENGINEER
02401
0938
Free Packets
Parameters::Base Comms::Ethernet
UDINT
0 to 100
NEVER
ENGINEER
02403
0939
Maximum Connections
Setup::Communications::Base Modbus
Parameters::Base Comms::Modbus
USINT 0 0 to 3 ALWAYS TECHNICIAN
02405
0940
High Word First
Same as PNO 939
BOOL
FALSE
ALWAYS
TECHNICIAN
02407
0941
Modbus Timeout
Same as PNO 939
TIME
3.000
0.000 to 65.000
s
ALWAYS
TECHNICIAN
02409
0942
Modbus Trip Enable
Same as PNO 939
BOOL
TRUE
ALWAYS
TECHNICIAN
02411
0943
Process Active
Monitor::Communications::Base Modbus
Parameters::Base Comms::Modbus
BOOL NEVER OPERATOR
02413
0944
Web Access
Setup::Communications::Base Ethernet
Setup::Environment
Parameters::Base Comms::Web Server
USINT
(enum)
1
0:DISABLED
1:LIMITED
2:FULL
ALWAYS TECHNICIAN
02415
0945
Web View Level Parameters::Base Comms::Web Server
USINT
(enum)
1
0:OPERATOR
1:TECHNICIAN
2:ENGINEER
ALWAYS OPERATOR
02417
0946
Web Password
Parameters::Base Comms::Web Server
STRING[16]
ALWAYS
ENGINEER
02419
0951
Boot Version
Parameters::Device Manager::Drive info
STRING[7]
NEVER
ENGINEER
02429
0955
Enable Predict Term
Parameters::Motor Control::Current Loop
BOOL
TRUE
ALWAYS
ENGINEER
02437
0957
Anin 01 Offset
Setup::Inputs and Outputs::Base IO
Parameters::Inputs And Outputs::IO Configure
REAL 0.00 Min to Max % ALWAYS OPERATOR
02441
0958
Anin 01 Scale
Same as PNO 957
REAL
1.0000
Min to Max
ALWAYS
OPERATOR
02443
0959
Anin 02 Offset
Same as PNO 957
REAL
0.00
Min to Max
%
ALWAYS
OPERATOR
02445
0960
Anin 02 Scale
Same as PNO 957
REAL
1.0000
Min to Max
ALWAYS
OPERATOR
02447
0961
Drive Name
Setup::Environment
Parameters::Device Manager::Drive info
STRING[23] ALWAYS TECHNICIAN 7
02449
