Parker AC30 series User Manual

D-144 Parameter Reference
AC30V series Variable Speed Drive
PNO
Name
Path(s)
Type
Default
Range
Units
WQ
View
Notes
MBus
0840
Warnings 1 - 32.11 HEATSINK OVERTEMP
Same as PNO 829
BOOL
NEVER
OPERATOR
02207
0841
Warnings 1 - 32.12 INTERNAL OVERTEMP
Same as PNO 829
BOOL
NEVER
OPERATOR
02209
0842
Warnings 1 - 32.13 MOTOR OVERTEMP
Same as PNO 829
BOOL
NEVER
OPERATOR
02211
0843
Warnings 1 - 32.14 EXTERNAL TRIP
Same as PNO 829
BOOL
NEVER
OPERATOR
02213
0844
Warnings 1 - 32.15 BRAKE SHORT CCT
Same as PNO 829
BOOL
NEVER
OPERATOR
02215
0845
Warnings 1 - 32.16 BRAKE RESISTOR
Same as PNO 829
BOOL
NEVER
OPERATOR
02217
0846
Warnings 1 - 32.17 BRAKE SWITCH
Same as PNO 829
BOOL
NEVER
OPERATOR
02219
0847
Warnings 1 - 32.18 LOCAL CONTROL
Same as PNO 829
BOOL
NEVER
OPERATOR
02221
0848
Warnings 1 - 32.19 COMMS BREAK
Same as PNO 829
BOOL
NEVER
OPERATOR
02223
0849
Warnings 1 - 32.20 LINE CONTACTOR
Same as PNO 829
BOOL
NEVER
OPERATOR
02225
0850
Warnings 1 - 32.21 PHASE FAIL
Same as PNO 829
BOOL
NEVER
OPERATOR
02227
0851
Warnings 1 - 32.22 VDC RIPPLE
Same as PNO 829
BOOL
NEVER
OPERATOR
02229
0852
Warnings 1 - 32.23 BASE MODBUS BREAK
Same as PNO 829
BOOL
NEVER
OPERATOR
02231
0853
Warnings 1 - 32.24 24 V OVERLOAD
Same as PNO 829
BOOL
NEVER
OPERATOR
02233
0854
Warnings 1 - 32.25 PMAC SPEED ERROR
Same as PNO 829
BOOL
NEVER
OPERATOR
02235
0855
Warnings 1 - 32.26 OVERSPEED
Same as PNO 829
BOOL
NEVER
OPERATOR
02237
0856
Warnings 1 - 32.27 STO ACTIVE
Same as PNO 829
BOOL
NEVER
OPERATOR
02239
0857
Warnings 1 - 32.28 FEEDBACK MISSING
Same as PNO 829
BOOL
NEVER
OPERATOR
02241
0858
Warnings 1 - 32.29 INTERNAL FAN FAIL
Same as PNO 829
BOOL
NEVER
OPERATOR
02243
0859
Warnings 1 - 32.30 CURRENT SENSOR
Same as PNO 829
BOOL
NEVER
OPERATOR
02245
0860
Warnings 1 - 32.31 POWER LOSS STOP
Same as PNO 829
BOOL
NEVER
OPERATOR
02247
0895
Recent Trips
Parameters::Trips::Trips History
ARRAY[0..9]
NEVER
OPERATOR
02317
0896
Recent Trips[0] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02319
0897
Recent Trips[1] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02321
0898
Recent Trips[2] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02323
0899
Recent Trips[3] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02325
0900
Recent Trips[4] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02327
0901
Recent Trips[5] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02329
0902
Recent Trips[6] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02331
0903
Recent Trips[7] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02333
0904
Recent Trips[8] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02335
0905
Recent Trips[9] Parameters::Trips::Trips History
USINT
(enum)
Same as PNO 696 NEVER OPERATOR 1
02337
0906
Stall Limit Type Parameters::Trips::Stall Trip
USINT
(enum)
2
0:TORQUE
1:CURRENT
2:TORQUE OR CURRENT
ALWAYS TECHNICIAN
02339
0907
Stall Time
Parameters::Trips::Stall Trip
TIME
120.000
0.100 to 2000.000
s
ALWAYS
TECHNICIAN
6
02341
0908
Control Screen Mode Parameters::Device Manager::Soft Menus
USINT
(enum)
1
0:DISABLED
1:AUTO
2:CUSTOM
STOPPED ENGINEER
02343
0909
Stall Torque Active
Parameters::Trips::Stall Trip
BOOL
NEVER
TECHNICIAN
02345
0910
Stall Current Active
Parameters::Trips::Stall Trip
BOOL
NEVER
TECHNICIAN
02347
0911
Stall Speed Feedback
Parameters::Trips::Stall Trip
REAL
x.
-200 to 200
%
NEVER
ENGINEER
02349
0912
VDC Ripple Filter TC
Parameters::Trips::VDC Ripple
TIME
1.000
0.100 to 100.000
s
ALWAYS
ENGINEER
02351
0913
Max VDC Ripple
Parameters::Trips::VDC Ripple
REAL
x.
0 to 500
V
NEVER
ENGINEER
02353
0914
VDC Ripple Trip Delay
Parameters::Trips::VDC Ripple
TIME
0.000 to 300.000
s
NEVER
ENGINEER
02355
0915
VDC Ripple Trip Hyst
Parameters::Trips::VDC Ripple
REAL
10
0 to 50
V
ALWAYS
ENGINEER
02357
