PREVOST LE MIRAGE XLII BUS SHELLS User Manual

7
62--11053
7 SHAFT SEAL RESERVOIR AND SHAFT END FLANGES
1
11
12
7
6
5
4
3
2
5
11
12
8
10
9
Item Part Number Description Qty
1 05GA503-724 Access Valve, Coreless, 7/16-20, With O-Ring 1
2 17-44771-00 Reservoir, Shaft Seal 1
3 05GA503-734 Washer, Internal Tooth, 3/8 Inch, Plated 1
4 AA06GS228 Cap Screw, Hex Head, 3/8-16 X 0.75 Inch Long, Grade 8 1
5 17-44119-00
Gasket, End Flange, Ultra Style or Full Ring Flange (Used With Items 6
and 7)
1
6 17-44025-00 End Flange, Ultra Style (Trailer) 1
7 17-44002-00 End Flange, Full Ring (Star Flange) 1
8 17-44127-00 End Flange, Half Moon (Bus) 1
9 17-44118-00 Gasket, Half Moon End Flange (Used Only With Item 8) 1
10 17-44014-00 Gasket, Flange Spacer (Used Only With Items 8 and 9) 2
11 17-10308-00 Cap Screw, Hex Head, 3/8-16 X 1.25 Inch Long, Grade 5 A/R
12 17-40019-00 Gasket, Cap Screw A/R
