Section 11: REAR AXLES
PA1553
10
3. SPECIFICATIONS
Drive Axle
Make............................................................................................................................................................Meritor
Drive track........................................................................................................................ 76.7 inches (1 949 mm)
Gear type.....................................................................................................................................................Hypoid
Axle type.............................................................................................................................................. Full floating
Lube capacity .........................................................................................................................41 pints (19,3 liters)
Drive axle ratio
World Transmission
4.88:1 Standard
4.56:1 Optional
NOTE
The drive axle alignment consists in aligning the axle with reference to the frame. The axle must be
perpendicular to the frame.
Tag Axle
Make...........................................................................................................................................................Prévost
Rear track ........................................................................................................................ 83.6 inches (2 124 mm)
Axle type......................................................................................................Dana Spicer Europe TS8U Hub Unit
NOTE
The tag axle alignment consists in aligning the tag axle parallel to the drive axle.
