12
62--11053
11 CYLINDER HEAD (SIDE)
UNLOADER CYLINDER HEAD
STANDARD SHAVED CYLINDER HEAD
8
6
5
4
3
1
2
7
Item Part Number Description Qty
1 17-44743-00 Cylinder Head, Unloader - Side Banks 2
2 17-40108-00 Strainer 1
3 17-10224-05 Capscrew, Hex Head, 3/8 -16 x 3-1/4 Inches Long - SAE Grade 8 8
4 17-44017-00 Stud, Cylinder Head (Unloader or Center), 3/8 -16 x 4-1/4 Inches Long A/R
5 17-44753-00 Cylinder Head - Side Banks, Shaved (Standard, No Unloader) 2
6 17-44117-00 Capscrew, Hex Head , 3/8 -16 x 2-1/4 Inches Long - SAE Grade 8 6
7 AA06GR232 Capscrew, Hex Head, 3/8 -16 x 1-1/4 Inches Long - SAE Grade 8 2
8 17-44780-00 Stud, Cylinder Head (Shaved), 3/8 -16 x 3-1/4 Inches Long A/R
12 CYLINDER HEAD (CENTER)
1
13
12
11
10
9
8
7
6
5
4
3
2
Item Part Number Description Qty
1 17-40012-00 Capscrew, Hex Head, 5/16 -18 x 2 Inches Long - SAE Grade 8 2
2 17-40013-00 Gasket, Capscrew, 5/16 Inch 2
17-01042-04 Valve, Service 7/8 Inch ODF (1/8 Inch FPT Gauge Port)- Includes: 1
14-00206-01 Valve, Service 7/8 Inch ODF (M15 Gauge Port For R-134a) - Includes: 1
4 17-10812-00 Cap, Service Valve (Plastic) 1
17-10811-05 Gasket, Service Valve (Fiber) 1
17-44138-00 Gasket, Service Valve (Metal) 1
4 17-10806-10 Cap, Service Valve (Brass) 1
17-44752-00 Cylinder Head, Center Bank, One Pressure Port (Bus) 1
17-44754-00 Cylinder Head, Center Bank, Two Pressure Ports (T/T) 1
7 17-10224-05 Capscrew, Hex Head, 3/8 -16 x 3 -1/4 Inches Long - SAE Grade 8 8
8 CA63AA051 Pipe Plug, 1/4 -18NPT (package of 20) A/R
9 17-13004-00 Kit, Valve Pad Blank Off, 2 Bolt Suction Service Valve 1
10 17-13022-00 Packing, Service Valve Stem 1
11 40-00524-01 Elbow, 1/8 MPT x M15 - Brass (for R -134a) 1
12 40-00520-01 Coupling, M15, High Side - Brass - Includes: 1
13 40-00520-03 Cap, Service Port 1
11 40-00060-08 Elbow, 1/8 MPT x 1/4 FPT - Brass (for R -12, R -22) 1
12 06DA403-844 Valve, Access (1/4 Flare, Schrader) 1
13 DD19CA061 Cap, 1/4 Flare, Schrader 1
