PREVOST LE MIRAGE XLII BUS SHELLS User Manual

19
62--11053
16 CLUTCH ASSEMBLY - SHAFT MOUNTED
Item Part Number Description Qty
50-01108-00 Clutch, 24 VDC, 2-C Grooves, 9 Inch Diameter
5
50-01110-00 Clutch, 24 VDC, 3-3V Grooves, 8.48 Inch Diameter
1
5
50-01110-01 Clutch, 12 VDC, 3-3V Grooves, 8.48 Inch Diameter
1
50-01114-00 Clutch, 12 VDC, 2-B Grooves, 8.64 Inch Diameter
6
50-50011-00 Coil, 24 VDC
1
6
50-50014-00 Coil, 12 VDC
1
7 50-50015-00 Ring, Retaining - External 1
8 50-50016-00 Ring, Retaining - Internal 1
9 50-50017-00 Bearing 1
10 17-10308-00 Capscrew, Hex Head, 3/8-16 x 1-1/4 Inches Long - SAE Grade 8 2
11 68-G---2--8522-1 Spacer, 1-3/8 OD x 1/2 Inch Thick - CRES 2
12 17-40324-00 Key, Crankshaft, 1/4 x 1/4 x 1-1/2 Inches Long 1
13 50-01115-00 Plate, Adapter (Used with 50-01114 Clutch) 1
14 68-G---2--1823
Sheave, Power Takeoff, 3-3V Grooves, 6 Inch Diameter, ( On Allison
Transmission)
1
