PREVOST LE MIRAGE XLII BUS SHELLS User Manual

13
62--11053
13 GASKET SET
8
6
11
9
10
7
5
4
3
2
1
Item Part Number Description Qty
- 17-44775-00 Gasket Set, Metal - Includes: 1
1 17-44141-00 Gasket, Suction Service Valve - 4 Bolt 1
2 17-44004-06 Gasket, Shaft Seal 1
3 17-44746-00 Gasket, Valve Plate 3
4 17-44118-00 Gasket, End Flange 1
5 17-44119-00 Gasket, End Flange 1
6 17-44129-00 Gasket, Bottom Plate 1
7 17-44747-00 Gasket, Cylinder Head, Center or Side Banks 3
8 17-44022-00 Gasket, Pump End Bearing Head 1
9 17-40104-07 Gasket, Unloader Body 2
10 17-44021-00 Gasket, Sight Glass 2
11 17-44138-00 Gasket, Service Valve - 2 Bolt 2
