FAULT CODE MANUAL Created on 00-04-25 15:30
- 20 -
15. Fault codes, ZF HP 502 retarder (MID 222) and transmission (MID 130)
MID (P)PID/SID FMI Seriousness Component/function Display text
130 PID 1 0 Transmission slip
Invalid data
130 PID 155 3 Not used dig. Out shorted high Aux. input/output 1
130 PID 155 12 Internal I/O safety switch error Aux. input/output 1
130 PID 161 2 Turbine speed level error Input shaft speed
130 PID 161 11 Turbine speed measuring overflow Input shaft speed
130 PID 177 0 Transmission oil temperature high Transm. oil temp.
130 PID 177 3 Transmission temperature sensor above Transm. oil temp.
130 PID 177 4 Transmission temperature sensor below Transm. oil temp.
130 PID 191 2 Output speed level error Output shaft speed
130 PID 191 11 Output speed measuring overflow Output shaft speed
130 SID 1 3 Solenoid valve B shorted high Solenoid valve #1
130 SID 1 4 Solenoid valve B shorted ground Solenoid valve #1
130 SID 1 5 Solenoid valve B circuit break Solenoid valve #1
130 SID 2 3 Solenoid valve C shorted hig Solenoid valve #2
130 SID 2 4 Solenoid valve C shorted ground Solenoid valve #2
130 SID 2 5 Solenoid valve C circuit break Solenoid valve #2
130 SID 225 3 Operating lamp shorted high Green lamp
130 SID 225 4 Operating lamp shorted ground Green lamp
130 SID 253 2 Operating time counter checktime error Calibration memory
130 SID 253 11 Statistik memory checksum error Calibration memory
130 SID 253 12 Error read error memory Calibration memory
130 SID 254 11 Internal system error Controller #1
130 SID 3 3 Solenoid valve D shorted high Solenoid valve #3
130 SID 3 4 Solenoid valve D shorted ground Solenoid valve #3
130 SID 3 5 Solenoid valve D circuit break Solenoid valve #3
130 SID 4 3 Solenoid valve E shorted high Solenoid valve #4
130 SID 4 4 Solenoid valve E shorted ground Solenoid valve #4
130 SID 4 5 Solenoid valve E circuit break Solenoid valve #4
130 SID 5 3 Solenoid valve F shorted high Solenoid valve #5
130 SID 5 4 Solenoid valve F shorted ground Solenoid valve #5
130 SID 5 5 Solenoid valve F circuit break Solenoid valve #5
130 SID 55 2 D1 current resistor Clutch actuator
130 SID 55 3 D1 current shorted high Clutch actuator
130 SID 55 4 D1 current shorted ground Clutch actuator
130 SID 55 5 D1 current circuit break Clutch actuator
130 SID 6 3 Solenoid valve G shorted high Solenoid valve #6
130 SID 6 4 Solenoid valve G shorted ground Solenoid valve #6
130 SID 6 5 Solenoid valve G circuit break Solenoid valve #6
130 SID 7 3 Torque converter clutch shorted high Lockup sol.valve
130 SID 7 4 Torque converter clutch shorted ground Lockup sol.valve
130 SID 7 5 Torque converter clutch circuit break Lockup sol.valve
130 SID 8 3 Solenoid valve A shorted high Forward sol. valve
130 SID 8 4 Solenoid valve A shorted ground Forward sol. valve
130 SID 8 5 Solenoid valve A circuit break Forward sol. valve
222 PID 1 3 U_Ret shorted high
Invalid data
222 PID 1 4 U_Ret shorted ground
Invalid data
222 PID 62 14 Reduction of retarder function active Retard inhibit stat
222 PID 120 0 Retarder oil temperature high Hyd retard oil temp
222 PID 120 3 Retarder temperature sensor above Hyd retard oil temp
222 PID 120 4 Retarder temperature sensor below Hyd retard oil temp
222 SID 10 3 Ret_On Valve shorted high ?
