1 Specifications
Continued on next page
Alcoa aluminum disc wheel mounting dimensions are consistent with SAE Recommended Practice J694 February 2001. Part numbers listed for all sizes are satin finish. Polished
finishes are indicated by changing the last digit of the part number listed to one of the following. For polished outside only, part number should end in “1.” For polished inside only,
part number should end in “2.” For polished both sides, part number should end in “3.” Valve hole is on the inside. Only for item numbers marked with an asterisk(*), part numbers
ending in “9” are inset position wheels satin finished (see footnote).
Dura-Bright
®
surface treatment wheels are identified by using the regular numerical part number and the addition of “DB” at the end. Finishes are indicated by changing the last
numerical digit of the part number to one of the following. For brushed both sides, the number is “0.” For buffed outside only, the number is “1.” For buffed inside only, the number
is “2.” For buffed both sides, the number is “3.” Currently, only the wheel item numbers marked with “DB” are available with the Dura-Bright
®
surface treatment. Dura-Flange
®
wheels
are identified by using the regular numerical part number and the addition of “DF” at the end. Only the wheel item numbers marked with DF are available with the Dura-Flange
®
option
and are available in all polished finishes.
TUBELESS WHEELS (round hand holes) ENGLISH UNITS
Item no. Wheel description
Maximum
wheel load
1
in lbs.
Wheel wt.
lbs.
Outset
inches
3
Inset
inches
Maximum
inflation
PSI—cold
Valve
stem
Part
number
2
DiscMate Stabilizer
Front outer
cap nuts
Rear inner
cap nuts
Al/Al
Rear inner
cap nuts
Al/Stl
Rear outer
cap nuts
Lug nut
covers
Hub cover
system
kits front / rear
Six-hole, stud located, ball seat mounting—8.750 in. bolt circle, 6.495 in. hub bore, 1.219 in. bolt hole diameter
1 17.5x6.75-15°DC
5070 32 5.55 4.72 125
TR543C 663170 -
2125
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
5988 L&R 7896 L&R 5996 L&R
150 -
10-hole, stud located, ball seat mounting—8.750 in. bolt circle, 6.495 in. hub bore, 1.219 in. bolt hole diameter
2 17.5x6.75-15°DC
5070 31 5.55 4.72 125
TR543C 663070 -
2125
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
5988 L&R 7896 L&R 5996 L&R
150 -
10-hole, stud located, ball seat mounting—11.25 in. bolt circle, 8.73 in. hub bore, 1.219 in. bolt hole diameter
3 22.5x7.50-15°DC 7200 53 6.28 5.32 120 TR545D 873100
3/4" - 016000,
1-1/8" 017000
2225
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
5988 L&R 7896 L&R 5996 L&R 150
Front - 076015
Rear - 077015
DB
4 22.5x8.25-15°DC 7200 53 6.66 5.68 120 TR545D 883110
3/4" - 016000,
1-1/8" 017000
2225
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
5988 L&R 7896 L&R 5996 L&R 150
Front - 076015
Rear - 077015
5 22.5x9.00-15°DC 9000 60 6.94 5.94 130 TR543C 893000
3/4" - 016000,
1-1/8" 017000
2127
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
5988 L&R 7896 L&R 5996 L&R 150
Front - 076015
Rear - 077015
6 22.5x12.25-15°DC 11,400 62
.56
Reversible
— 125 TR543E 823000
3/4" - 016000,
1-1/8" 017000
-
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
--
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
150
Front - 076015
Rear - 077015
*7 22.5x12.25-15°DC 11,400 66 3.88 2.76 125
TR543E
outset
TR545E
inset
823050
3/4" - 016000,
1-1/8" 017000
-
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
--
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
150
Front - 076015
Rear - 077015
8 22.5x12.25-15°DC 11,000 70 5.84 4.68 120 TR545E 823060A
3/4" - 016000,
1-1/8" 017000
-
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
--
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
150
Front - 076015
Rear - 077015
9 22.5x13.00-15°DC 12,300 72 3.5 2.38 125 TR543E 833050
3/4" - 016000,
1-1/8" 017000
-
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
--
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
150
Front - 076015
Rear - 077015
*
††
10 22.5x14.00-15°DC 12,800 71 2.0 0.87 125
TR543E
outset
TR545E
inset
841100
3/4" - 016000,
1-1/8" 017000
-
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
--
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
150
Front - 076015
Rear - 077015
11 24.5x8.25-15°DC 7200 59 6.6 5.59 120 TR545D 983120
3/4" - 016000,
1-1/8" 017000
-
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
5988 L&R 7896 L&R
3/4" Stud 5995 L&R,
1-1/8" Stud 5996 L&R
150
Front - 076015
Rear - 077015
10-hole, stud located, ball seat mounting—13.19 in. bolt circle, 10.65 in. hub bore (valve hole is on outside), 1.360 in. bolt hole diameter
4
12 22.5x13.00-15°DC 11,000 76 — 6.12 120 TR543 833070A -
--
--
-
-
-
Eight-hole, hub piloted mounting—275mm bolt circle, 221.1mm hub bore, 26.75mm bolt hole diameter (use two-piece flange nuts)
DB
13 22.5x7.50-15°DC 7300 53 6.28 5.44 120 TR545D 873400 014000 2225 39874 - - 39874 181 -
DF
**14
22.5x8.25-15°DC 7300 50 6.66 5.82 120 TR545D 883420 014000 2227 39874 - - 39874 181 -
DB DF
**15
22.5x8.25-15°DC 7400 50 6.66 5.82 130 TR544D 883440 014000 8344 39874 - - 39874 181 -
*
††
16 22.5x14.00-15°DC 12,800 71 2.0 0.87 125
TR543E
outset
TR545E
inset
841400 014000 - 39874 - - 39874 181 -
17 24.5x8.25-15°DC 7300 62 6.6 5.77 120 TR509 983400 014000 2245 39874 - - 39874 181 -
