SmartStor NS4600 Product Manual
110
The original file structure is maintained during backup and restoration.
To restore your backed-up files from the NAS system to your PC:
1. Go to the Main Window.
2. Click the SmartSYNC icon. (A)
3. Click the Restore button. (B)
4. Click the folder whose contents you want to restore. (C)
Click the arrow icons to expand the tree and narrow your choices. (D)
5. Click an option button for:
• Restore to original folder – The backup files will overwrite the files on
your PC (E)
• Restore to a specific folder – No files are overwritten on your PC (E)
6. If you chose Restore to a specific folder, do one of the following actions:
• Type the name of an existing folder in the field provided
Caution
If you restore to the original folders on your PC, the restore
function will overwrite the files in those folders.
Be careful which files you restore and where on your PC you direct
the backup files.

Promise Technology Smartstor NS4600 Specifications

General

RAID levels	0, 1, 5, 10
Storage drive size	3.5 \
Hot-swap drive bays	Yes
Storage drive capacity	0 GB
Supported file systems	EXT3, FAT32
Storage drive interface	Serial ATA II
Total installed storage capacity	0 TB
Number of storage drives installed	4
Internal memory	0.25 GB
Processor model	-
Processor frequency	0.6 GHz
Maximum data transfer rate	1000 Mbit/s
Supported network protocols	FTP, DHCP, NTP
Compliance industry standards	IEEE 802.3i, IEEE 802.3ab, IEEE 802.3u
Certification	RoHS, CE, FCC, UL, TUV
Data transfer rate	3 Gbit/s
Dimensions (WxDxH)	152.5 x 229.6 x 188.2 mm
Power requirements	100 - 230 V/50-60 Hz
Networking features	Gigabit Ethernet
Compatible operating systems	Windows 2000/XP/2003/Vista Mac x 10.4 + Linux
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Power supply unit (PSU) capacity	90 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	2500 g
