R&S ESR Series User Manual

System Configuration
R&S
®
ESR
515User Manual 1175.7068.02 ─ 12
Furthermore, some special GPIB settings are available to emulate HP models (see
Chapter 11.18, "GPIB Commands of HP Models 856xE, 8566A/B, 8568A/B and
8594E", on page 1039):
●
"GPIB Language" on page 515
●
"IF Gain (Norm/Puls)" on page 516
●
"Sweep Repeat (On/Off)" on page 516
●
"Coupling (FSx/HP)" on page 517
"Default"
Standard R&S ESR operation, see "Mode Default" on page 515
"R&S FSP"
Compatible to R&S FSP, see "Mode R&S FSP" on page 515
"R&S FSU"
Compatible to R&S FSU, see "Mode R&S FSU" on page 515
Remote command:
SYSTem:COMPatible on page 920
Mode Default ← Compatibility Mode ← GPIB ← General Setup
Resets the number of measurement points and available bandwidths to default
R&S ESR values.
Remote command:
SYST:COMP DEF, see SYSTem:COMPatible on page 920
Mode R&S FSP ← Compatibility Mode ← GPIB ← General Setup
Sets the number of measurement points and available bandwidths as in R&S FSP
devices.
Remote command:
SYST:COMP FSP, see SYSTem:COMPatible on page 920
Mode R&S FSU ← Compatibility Mode ← GPIB ← General Setup
Sets the number of measurement points and available bandwidths as in R&S FSU
devices.
Remote command:
SYST:COMP FSU, see SYSTem:COMPatible on page 920
GPIB Language ← Compatibility Mode ← GPIB ← General Setup
Opens a list of selectable remote-control languages:
Language Comment
SCPI
71100C Compatible to 8566A/B
71200C Compatible to 8566A/B
71209A Compatible to 8566A/B
8560E
8561E
8562E
8563E
Instrument Setup and Interface Configuration – SETUP Key
