12 Rockwell Automation Publication 2198-UM002L-EN-P - October 2021
Preface
Conventions Used in This
Manual
These conventions are used throughout this manual:
• Bulleted lists such as this one provide information, not procedural steps
• Numbered lists provide sequential steps or hierarchical information
• When catalog number 2198-xxxx-ERS3 appears in this publication
without series designation, the topic applies to series A and B drives
• The 2198-CAPMOD-2240 capacitor module, 2198-CAPMOD-DCBUS-IO
extension module, and 2198-DCBUSCOND-RP312 DC-bus conditioner
module are collectively referred to as accessory modules
CIP Security
CIP Securityâ„¢ is a standard, open-source communication method that helps to
provide a secure data transport across an EtherNet/IP network. It lets
CIP-connected devices authenticate each other before transmitting and
receiving data.
CIP Security uses the following security properties to help devices protect
themselves from malicious communication:
• Device Identity and Authentication
• Data Integrity and Authentication
• Data Confidentiality
Rockwell Automation uses the following products to implement CIP Security:
• FactoryTalk® Services Platform, version 6.11 or later, with the following
components enabled:
– FactoryTalk Policy Manager
– FactoryTalk System Services
• FactoryTalk Linx, version 6.11 or later
• Studio 5000® Design Environment, version 32.00.00 or later
• CIP Security-enabled Rockwell Automation® products, for example, the
product described in this publication
For more information on CIP Security, including which products support CIP
Security, see the CIP Security with Rockwell Automation Products Application
Technique, publication SECURE-AT001
.
IMPORTANT
Throughout this publication, when the Kinetix 5700 inverter
catalog number ends in -ERSx, for example 2198-D057-ERSx, the
variable (x) indicates that the inverter (using this example) can be
2198-D057-ERS3 or 2198-D057-ERS4.
