Rockwell Automation Publication 2198-UM002L-EN-P - October 2021 39
Chapter 2
Plan the Kinetix 5700 Drive System Installation
This chapter describes system installation guidelines used in preparation for
mounting your Kinetix® 5700 drive system components.
System Design Guidelines Use the information in this section when planning to mount your system
components on the panel.
For on-line product selection and system configuration tools, including
AutoCAD (DXF) drawings of the product, refer to
https://www.rockwellautomation.com/global/support/selection.page
.
System Mounting Requirements
• To comply with UL and CE requirements, the Kinetix 5700 drive system
must be mounted in a grounded conductive enclosure offering
protection as defined in standard IEC 60529 to IP20 such that they are
not accessible to an operator or unskilled person.
To maintain the functional safety rating of the Kinetix 5700 drive system,
this enclosure must be appropriate for the environmental conditions of
the industrial location and provide a protection class of IP54 or higher.
• The panel you install inside the enclosure for mounting your system
components must be on a flat, rigid, vertical surface that won’t be
subjected to shock, vibration, moisture, oil mist, dust, or corrosive vapors
in accordance with pollution degree 2 (EN 61800-5-1) because the product
is rated to protection class IP20 (EN 60529).
• Size the system enclosure so as not to exceed the maximum ambient
temperature rating. Consider heat dissipation specifications for all
system components.
Topic Page
System Design Guidelines 39
Accessory Module Selection 56
Electrical Noise Reduction 64
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful
to keep metal debris from falling into it. Metal debris or other foreign matter
can become lodged in the circuitry and result in damage to the components.
