Rockwell Automation Allen-Bradley Kinetix 5700 User Manual

Rockwell Automation Publication 2198-UM002L-EN-P - October 2021 91
Chapter 4
Connector Data and Feature Descriptions
This chapter illustrates connectors and indicators for the Kinetix® 5700 drive
system components, including the DC-bus power supply, regenerative bus
supply, single-axis inverter, dual-axis inverter, and accessory modules. Also
included in this chapter are connector pinouts and descriptions for
Kinetix 5700 system components.
Topic Page
Kinetix 5700 Connector Data 92
Understand Control Signal Specifications 105
Feedback Specifications 111
Functional Safety Features 118
