Rockwell Automation Allen-Bradley Kinetix 5700 User Manual

Rockwell Automation Publication 2198-UM002L-EN-P - October 2021 353
Appendix A Interconnect Diagrams
System Block Diagrams This section provides block diagrams of the Kinetix 5700 drive modules.
Figure 193 - DC-bus Power Supply Block Diagram
(1) Ground screw in the installed (default) configuration.
L1
L2
L3
DC+
DC–
SH
DC+
24V+
24V–
CONT EN–
CONT EN+
Three-phase
Input Power
(IDP) Connector
24V Control Power
(CP) Connector
Ground Screw
(1)
Control
Chassis
Contactor Enable
(CED) Connector
DC Bus Power
(DC) Connector
Shunt Resister
(RC) Connector
Internal Shunt
Resistor
