Rockwell Automation Publication 2198-UM002L-EN-P - October 2021 275
Chapter 8
Remove and Replace Drive Modules
This chapter provides remove and replace procedures for Kinetix® 5700 drive
modules.
Before You Begin When each drive module is installed, network settings are configured from the
setup screens. Before removing the module, revisit the Network menu and
make note of the static IP or DHCP settings. Refer to Configure the Drive
on
page 188
to access those settings.
You also need these tools available before you begin removal and replacement
procedures:
• Screwdrivers (to loosen/remove screws)
• Voltmeter (to make sure that no voltage exists on drive connectors)
Topic Page
Before You Begin 275
Remove and Replace Kinetix 5700 Drive Modules 276
Start and Configure the Drive Module 280
ATTENTION: This drive contains electrostatic discharge (ESD) sensitive
parts and assemblies. You are required to follow static-control precautions
when you install, test, service, or repair this assembly. If you do not follow
ESD control procedures, components can be damaged. If you are not
familiar with static control procedures, refer to Guarding Against
Electrostatic Damage, publication 8000-4.5.2
, or any other applicable ESD
awareness handbook.
IMPORTANT
If you intend to use the same Logix Designer application after replacing
your drive module, the new module must be the same catalog number
as the old module.
