182 Rockwell Automation Publication 2198-UM002L-EN-P - October 2021
Chapter 6 Configure and Start the Kinetix 5700 Drive System
Setup Screens
The setup screens provide the means of changing drive settings, for example,
the IP address. Press one of the setup buttons to access the setup screens.
You can use the soft menu items and navigation buttons to
view the information and make changes.
Press to validate your changes:
• If the change is invalid, the value doesn’t change.
• If the change is valid, an asterisk appears next to the
changed attribute.
Table 109 - Navigating the iTRAK Power Supply Menu
Menu/Sub Menu
Selections
Attributes Description Example Values
Module Info
Catalog number 2198T-W25K-ER
Firmware revision FW: 6.1.7100254
Hardware revision HW REV: 1.1
Serial number SERIAL#: xxxxxxxxxxx
Diagnostics>
Converter Diagnostics
Bus diagnostics BUS VOLT: 0.0V
Output 1 diagnostics
OUT1 VOLT: 0.0V
OUT1 AMPS: 0.0A
OUT1 PWR: 0.0kW
OUT1 UTIL: 0.0%
Output 2 diagnostics
OUT2 VOLT: 0.0V
OUT2 AMPS: 0.0A
OUT2 PWR: 0.0kW
OUT2 UTIL: 0.0%
Converter diagnostics TOTAL PWR: 0.0kW
Fault Log
Fault text
Fault code as listed in the Kinetix 5700 Fault Codes.xlsx file.
(1)
FLT S38 - FUSE BLOWN
Fault details
The problem as reported in the Kinetix 5700 Fault Codes.xlsx file.
(1)
The internal DC-bus power fuse is blown
Fault help
The Possible Solution as reported in the Kinetix 5700 Fault Codes.xlsx file.
(1)
Return drive for repair if fault continues
(1) For Kinetix 5700 fault code descriptions and possible solutions, see Kinetix 5700 Servo Drive Fault Codes, publication 2198-RD003
.
IMPORTANT
You must cycle control power to make network configuration
changes persistent. In this example, the IP address was changed. The
change takes affect and the asterisk disappears after control power
is cycled.
Display configuration changes take effect immediately.
STATIC IP
SUBNET MASK
IP ADDRESS*
