Kinetix 5700 drive module catalog numbers and performance descriptions.
Table 4 - Kinetix 5700 Drive Module Catalog Numbers
Kinetix 5700 Drive
Modules
Cat. No.
Continuous Output
Current to Bus
A
DC
rms
Module
Width
mm
Continuous Output Power Output Current
240V Input
kW
480V Input
kW
Continuous
A 0-pk
Peak
A 0-pk
DC-bus Power Supply
(195…528V AC rms,
three-phase input power)
2198-P031
2198-P070
10.5
25.5
55
3.5
8.5
7
17
––
2198-P141
2198-P208
46.9
69.2
85
15.5
23.0
31
46
Regenerative
(1)
Power Supply
(324…506V AC rms,
three-phase input power)
2198-RP088 35.3 165 – 24
––
2198-RP200 100.0 275 – 67
2198-RP263 176.4
440
–119
2198-RP312 207.0 – 140
Single-axis Inverters
2198-S086-ERS3
2198-S130-ERS3
2198-S086-ERS4
2198-S130-ERS4
85
14.9
22.5
29.7
44.9
60.8
91.9
121.6
183.8
2198-S160-ERS3 2198-S160-ERS4 100 30.1 60.1 120.2 226.2
2198-S263-ERS3
2198-S312-ERS3
2198-S263-ERS4
2198-S312-ERS4
220
45.0
56.0
90
112
212.1
271.5
371.9
441.2
Dual-axis Inverters
2198-D006-ERS3
2198-D012-ERS3
2198-D020-ERS3
2198-D032-ERS3
2198-D006-ERS4
2198-D012-ERS4
2198-D020-ERS4
2198-D032-ERS4
55
0.9
1.7
2.8
4.5
1.7
3.4
5.5
8.9
3.5
7.0
11.3
18.3
8.8
17.6
28.2
45.9
2198-D057-ERS3 2198-D057-ERS4 85 8.0 15.9 32.5 81.3
iTRAK Power Supply 2198T-W25K-ER 100 – – 2x12.5 2x12.5
(1) Applies when DC-bus voltage regulation is enabled. If DC-bus voltage regulation is not enabled, the input voltage range is 324….528V AC. For more information on these two modes of
operation, see DC-bus Voltage Regulation
on page 40.
Table 5 - Accessory Module Catalog Numbers
Accessory Modules
(1)
Cat. No.
Module
Width
mm
System Current
(2)
Rated Voltage Capacitance
Capacitor Module 2198-CAPMOD-2240
55 104 A 276…747V DC, nom
2240 µF
Extension Module 2198-CAPMOD-DCBUS-IO
–
DC-bus Conditioner Module 2198-DCBUSCOND-RP312
(1) Combination of any two accessory modules increases system current up to 208 A. However, modules must be mounted side-by-side and joined by two flexible bus-bars.
(2) Flexible bus-bars are included with only the 2198-CAPMOD-DCBUS-IO extension module. So, if you have two capacitor modules, two DC-bus conditioner modules, or a capacitor module and
DC-bus conditioner module mounted side by side, you must order the 2198-KITCON-CAPMOD2240 or 2198-KITCON-DCBUSCOND connector set separately.
