Rockwell Automation Allen-Bradley Kinetix 5700 User Manual

266 Rockwell Automation Publication 2198-UM002L-EN-P - October 2021
Chapter 7 Troubleshoot the Kinetix 5700 Drive System
Table 138 - DC-bus Power Supply Behavior, FLT Sxx Fault Codes
Exception Fault Code Exception Text
Fault Action
Best Available
Stopping Action
(applies to major faults)
Ignore Alarm Minor Fault Major Fault
FLT S15 – CONV OVERCURRENT Converter Overcurrent Fault – – – X
DC-bus power supply does
not perform stopping
actions.
FLT S16 – GROUND CURRENT Ground Current Factory Limit Fault – – – X
FLT S18 – CONV OVERTEMP FL Converter OverTemp Factory Limit Fault – – – X
FLT S20 – CONV OVERLOAD FL Converter Thermal OverLoad Factory Limit Fault – – – X
FLT S21 – CONV OVERLOAD UL Converter Thermal Overload User Limit Fault X X X X
FLT S23 – AC PHASE LOSS AC Single Phase Loss Fault – – – X
FLT S25 – PRECHARGE FAILURE Precharge Failure Fault – – – X
FLT S27 – BUS REG OVERTEMP FL
(1)
Bus Regulator Overtemperature Factory Limit
Fault
–––X
FLT S29 – BUS REG OVERLOAD FL
Bus Regulator Thermal OverLoad Factory Limit
Fault
–––X
FLT S30 – BUS REG OVERLOAD UL Bus Regulator Thermal Overload User Limit Fault X X X X
DC-bus power supply does
not perform stopping
actions.
FLT S31 – BUS REG FAILURE Bus Regulator Failure – – – X
FLT S32 – BUS CAPACITOR MODULE
FAILURE
Bus Capacitor Module Failure X X X X
FLT S35 – BUS OVERVOLT FL Bus Overvoltage Factory Limit Fault – – – X
FLT S40 – BUS POWER SHARING FAULT Bus Power Sharing Fault – – – X
FLT S61 – ENABLE INPUT Enable Input Deactivated – – – X
(1) Supported when shunt thermal switch is connected to the power supply digital input and configured in the Logix Designer application.
Table 139 - DC-bus Power Supply Behavior, FLT Mxx Fault Codes
Exception Fault Code Exception Text
Fault Action
Best Available
Stopping Action
(applies to major faults)
Ignore Alarm Minor Fault Major Fault
FLT M12 – POWER CYCLE FL
(1)
Converter Precharge Overload Factory Limit Fault–––X
DC-bus power supply does
not perform stopping
actions.
FLT M26 – RUNTIME ERROR Runtime Error –––X
(1) Single-axis and dual-axis drives assert Bus Power Sharing Exception.
Table 140 - DC-bus Power Supply Behavior, NODE FLT Fault Codes
Exception Fault Code Exception Text
Fault Action
Best Available
Stopping Action
(applies to major faults)
Ignore Alarm Minor Fault Major Fault
NODE FLT 01 – LATE CTRL UPDATE Control Connection Update Fault – – – X
DC-bus power supply does
not perform stopping
actions.
NODE FLT 02 – PROC WATCHDOG Processor Watchdog Fault – – – X
NODE FLT 03 – HARDWARE Hardware Fault – – – X
NODE FLT 05 – CLOCK SKEW FLT Clock Skew Fault – – – X
NODE FLT 06 – LOST CTRL CONN Lost Controller Connection Fault – – – X
NODE FLT 07 – CLOCK SYNC Clock Sync Fault – – – X
NODE FLT 09 – DUPLICATE IP ADDRESS Duplicate IP Address Fault – – – X
