Chapter 7 Troubleshoot the Kinetix 5700 Drive System
Table 144 - iTRAK Power Supply Behavior, FLT Sxx Fault Codes
Exception Fault Code Exception Text
Fault Action
Stopping Action
Ignore Alarm Minor Fault Major Fault
FLT S10 – INV OVERCURRENT Inverter Overcurrent Fault –––XShutdown
FLT S15 – CONV OVERCURRENT
(1)
Converter Overcurrent Fault –––XShutdown
FLT S16 - GROUND CURRENT FL Ground Current Factory Limit Fault –––XShutdown
FLT S18 - CONV OVERTEMP FL Converter OverTemp Factory Limit Fault –––XShutdown
FLT S20 - CONV OVERLOAD FL Converter Thermal Overload Factory Limit Fault –––XShutdown
FLT S21 – CONV OVERLOAD UL Converter Thermal Overload User Limit Fault XXXXHold
FLT S25 - PRECHARGE FAILURE Precharge Failure Fault –––XShutdown
FLT S31 - BUS REG FAILURE Bus Regulator Failure –––XShutdown
FLT S35 - BUS OVERVOLT FL Bus Overvoltage Factory Limit Fault –––XShutdown
FLT S38 - FUSE BLOWN Bus Power Fuse Blown Fault –––XShutdown
FLT S58 -BUS VOLTAGE ERROR Bus Voltage Error Fault –––XShutdown
FLT S61 - ENABLE INPUT Enable Input Deactivated –––XDisable
(1) All modules in the same bus group assert a Bus Power Sharing Exception if they are enabled.
Table 145 - iTRAK Power Supply Behavior, FLT Mxx Fault Codes
Exception Fault Code Exception Text
Fault Action
Stopping Action
Ignore Alarm Minor Fault Major Fault
FLT M26 - RUNTIME ERROR Runtime Error – – – X Shutdown
Table 146 - iTRAK Power Supply Behavior, NODE FLT Fault Codes
Exception Fault Code Exception Text
Fault Action
Stopping Action
Ignore Alarm Minor Fault Major Fault
NODE FLT 01 - LATE CTRL UPDATE Control Connection Update Fault – – – X Shutdown
NODE FLT 02 - PROC Processor Watchdog Fault – – – X Shutdown
NODE FLT 03 - HARDWARE Hardware Fault – – – X Shutdown
NODE FLT 05 - CLOCK SKEW FLT Clock Skew Fault – – – X Shutdown
NODE FLT 06 - LOST CTRL CONN Lost Controller Connection Fault – – – X Shutdown
NODE FLT 07 - CLOCK SYNC Clock Sync Fault – – – X Shutdown
NODE FLT 09 - DUPLICATE IP ADDRESS Duplicate IP address Fault – – – X Shutdown
