Section 07 ELECTRICAL SYSTEM
Subsection 05 (DIGITALLY ENCODED SECURITY SYSTEM (DESS))
Ensure the status bar shows the kW2000 and the
number 1 to the right. So that B.U.D.S. communi-
catewiththeECM,number1mustbedisplayed.
F18H0WA
kW2000
If an “X” is shown instead of a 1, this means that
no communication between MPI and ECM takes
place. Possible causes are:
– ECM is not powered-up
– wrong protocol is used
– bad connection between MPI and module.
Read ECM using READ DATA button.
Click on KEYS tab.
smr2005-072-001_en
Install key on MPI DESS post.
smr2005-072-002
ClickonADDKEYbuttonon
bottom of screen.
smr2005-072-003_Aen
1. Clickonthistab
A new key is now saved in the computer.
NOTE: To program other key(s), install a new key
on MPI DESS post and click again on ADD KEY
tab.
Ensure to save new data in ECM using WRITE
DATA button.
smr2005-072 217
