Shihlin electric SE3 Series User Manual

Appendix 1
APPENDIX 281
Parameter
Number
Group
Name
Setting Range
Default
Page
P.69
10-15
Auto reset times count
Read
0
217
P.70
06-06
Special regenerative brake
duty
0～100.0%
0.0%
153
P.71
00-13
Idling brake / DC brake
0: Idling brake
1
70
1: DC brake
P.72
00-11
Carrier frequency
1~15 kHz
5 kHz
69
P.73
02-08
Terminal 2-5 signal range
selection
0: Signal sampling range from 0 ~5V.
1
99
1: Signal sampling range from 0 ~10V.
2: Signal sampling range from 0 ~ -5V.
3: Signal sampling range from 0 ~ -10V.
4: Signal sampling range from -5～+5V.
5: Signal sampling range from -10～+10V.
P.74
02-43
Terminal HDO clock
multiplier factor
0: Select FM function as the output function of
terminal HDO.
0
108
1～9000: factor for square-wave pulse output
frequency.Value in 02-43 (P.74) times output
frequency will be actual output pulse frequency.
P.75
00-14
Stop function selection
0: Press STOP button and inverter stop running
in PU and H2 mode
1
70
1: Press STOP button and inverter stop running
in all mode.
P.77
00-03
Selection of parameters
write protection
0: Parameters can be written only when the
motor stops.
0
64
1: Parameters cannot be written.
2: Parameters can also be written when the
motor is running.
3: Parameters cannot be read when in password
protection.
P.78
00-15
Prevent forward/reverse
rotation selection
0: Forward/reverse rotation are both permitted.
0
71
1: Prevent reverse rotation (Giving reverse signal
decelerates and stops the motor).
2: Prevent forward rotation (Giving forward signal
decelerates and stops the motor).
P.79
00-16
Operation mode selection
0: “PU mode”, “external mode” and “Jog mode”
are interchangeable.
0
71
1: “PU mode” and “JOG mode” are
interchangeable.
2: “External mode” only
3: “Communication mode” only
4: “Combined mode 1”
5: “Combined mode 2”
6: “Combined mode 3”
7: “Combined mode 4
8: “Combined mode 5”
