Shihlin electric SE3 Series User Manual

Appendix 1
APPENDIX 282
Parameter
Number
Group
Name
Setting Range
Default
Page
P.79
00-16
Operation mode selection
99999: Second operation mode, run command is
set by 00-18(P.109), target frequency is set by
00-17(P.97)
0
71
P.80
03-03
Terminal M0 input function
Same as 03-00
2
119
P.81
03-04
Terminal M1 input function
Same as 03-00
3
119
P.82
03-05
Terminal M2 input function
Same as 03-00
4
119
P.83
03-00
Terminal STF input
function
0: STF(Inverter runs forward)
0
118
1: STR(Inverter runs reverse)
2: RL(Multi-speed low speed)
3: RM(Multi-speed medium speed)
4: RH(Multi-speed high speed)
5:AU( Analog terminal 4-5 high priority)
6: External thermal relay actuate
7: MRS(Stops inverter output immediately)
8: RT(Inverter second function)
9: EXT(External JOG)
10: STF+EXJ
11: STR+EXJ
12: STF+RT
13: STR+RT
14: STF+RL
15: STR+RL
16: STF+RM
17: STR+RM
18: STF+RH
19: STR+RH
20: STF+RL+RM
21: STR+RL+RM
22: STF+RT+RL
23: STR+RT+RL
24: STF+RT+RM
25: STR+RT+RM
26: STF+RT+RL+RM
27: STR+RT+RL+RM
28: RUN(Inverter runs forward)
29: STF/STR(use with RUN signal, when ON,
motor runs reverse；when OFF, motor runs
forward)
30: RES(External reset function)
31: STOP(Use as three line control with RUN
signal and STF-STR signal)
32: REX(Extend multi-speed to 16 levels)
