Rapidlab 1200 Operator’s Guide: Troubleshooting 6-35
02087462 Rev. V
Performing the Waste Detector Calibration
Use this procedure to calibrate the waste detector for the waste bottle.
1. Select Status > Diagnostics.
2. Enter your password, if necessary.
3. Select
Waste Detector.
4. Remove the waste bottle, empty it, and set it aside.
5. Select
Continue and wait while the system calibrates without the bottle.
6. Fill the waste bottle with tap water to the Max line.
7. Reinstall the bottle, and wait while the system calibrates with the full bottle.
8. Remove the waste bottle, empty it, and reinstall the empty bottle.
The system returns to the Diagnostics screen when finished.
9. To return to the Status screen, select
Return.
The systems perform a wash.
Calibrating the Touchscreen
Use this procedure to calibrate the touchscreen when the screen responds
inconsistently to selects. For example, if you must select to the left or the right
of
an item to select it, the touchscreen needs calibration.
1. Select Status > Diagnostics.
2. Enter your password, if necessary.
3. Select
Screen Calibration.
The screen displays a button.
NOTE: If you do not want to calibrate the touchscreen, do not touch the
screen. The system automatically returns to the Diagnostics menu after 30
seconds.
4. Select the button.
The button changes position on the screen.
5. Continue selecting the button again until the system returns to the Diagnostics
screen.
6. To return to the Status screen, select
Return.
CAUTION: Do not select any other part of the screen and do not select the button
more than once each time it appears. Touching any other part of the screen or
touching the button more than once causes the screen to become inoperable. If this
occurs, call for technical assistance.
