Simplex 4100ES Installation Guide

B-16
Appendix B
Step 3. Configuring Modules (continued)
UPS
Configuration
SW1-7. Controls battery charging current.
• Position 0: 50 Ah battery charging.
• Position 1: 110 Ah battery charging.
SW1-8. Not used.
DIP Switch SW2. Device address DIP switch. See Appendix A for details.
Use the following jumper settings to continue configuring the UPS.
P6. Battery backup configuration.
• Position 1 – 2: Normal configuration (battery backup).
• Position 2 – 3: No battery backup.
P7. Amplifier shutdown selection.
• Position 1 – 2: Tap A shutdown enabled.
• Position 3 – 4: Tap B shutdown enabled.
• Position 5 – 6: Tap C shutdown enabled.
P16. Controls Earth Detect configuration.
• Position 1 – 2: Enable Earth Detect.
• Position 2 – 3: Disable Earth Detect.
Note: Jumpers P10, P13, and JW1 through JW7 are not field adjustable.
Configuring Other
Cards
Refer to 4100/4100+ Fire Alarm Universal Transponder (UT) Service Instructions
(FA4-51-207) to configure other cards that are located in master controller bays and expansion
bays.
IMPORTANT: Do not use jumper P6 to bypass troubles from a
temporarily disconnected battery.

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
