Page #216 background imageLoading...
Page #216 background image
C-6
Appendix C
MINIPLEX System Guidelines
Overview The rules on this page apply exclusively to MINIPLEX systems. Review each guideline before
installing a MINIPLEX 4100 system.
Guidelines The MINIPLEX master control panel must be a 4100-8210 Voice and Sound Control
Panel.
The Style 4 RUI card supports MINIPLEX transponders and 4602/4603 serial
annunciators on the same signaling line circuit.
Up to 4 RUI cards in the 4100 Control Panel can be used for distributing transponder
wiring in different directions or for supporting different wiring requirements (such as
using a Style 7 RUI for serial annunciators).
Up to 31 MINIPLEX transponders can be controlled from the 4100 Control Panel, and can
be distributed as required among the RUI cards.
“T” tapping is allowed for Style 4 communications only (Style 7 wiring does not support
“T” tapping).
*Wiring from RUI cards is a minimum of 18 AWG twisted, shielded pair.
The maximum wiring distance from the 4100 RUI card to a MINIPLEX transponder is
2500 feet (762 m). For Style 4 wiring, this can be extended to 10,000 feet (3 km)
maximum if “T” tapping is used.
Voice and telephone wiring for 4100-8210 systems is via separate twisted, shielded pairs.
4100U system cards are not compatible with 4100 miniplex transponders that are
controlled by a 4100 RIC II card.
*The RUI+ has the same limitation as the RUI, except shielded wire is not required.
