1-18
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Telephones/
Microphones
The following phone and microphone assemblies are used with audio operator interfaces.
• 4100-1270 Master Telephone with Phone Card and 3 NACs (742-865)
• 4100-1271 Remote Master Telephone (742-597)
• 4100-1243 Microphone (742-523)
• 4100-1244 Remote Microphone (742-821)
• 4100-1265 Degraded Fail-Safe Mode Microphone Pre-Amp (Master – 743-238)
• 4100-1269 Degraded Fail-Safe Mode Microphone Pre-Amp (Slave – 743-306)
Additional Audio
Modules
Optional modules for the 4100ES audio system are listed below.
• 4100-0623 Network Audio Interface Module (742-522)
• 4100-1240 Aux Audio Input Board (742-388)
• 4100-1241 Audio Message Memory Expansion Module, 8 Minute (742-518)
• 4100-1242 Audio Message Memory Expansion Module, 32 Minute (742-393)
• 4100-1272 Telephone Expansion Card (742-600)
• 4100-1273 Class A Telephone Adapter Module (742-599)
• 4100-1274 Microphone Mux Module (743-808)
Common Audio
Options
• 4100-1245 Flex 50 Expansion NAC Board with 3 Class B NACs (742-540)
• 4100-1246 Flex 50 Class A Adapter (Converts 3 on-board NACs to Class A) (742-539)
• 4100-1248 100 Watt Expansion NAC Board with 6 Class B NACs (742-524)
• 4100-1249 100 Watt Class A Adapter (Converts 6 on-board NACs to Class A) (742-543)
• 4100-1259 Constant Supervision NAC 25 VRMS with 3 Class A/B Constant Supervision
NACs (Converts 3 on-board NACs to Constant Supervision) (743-163)
• 4100-1260 Constant Supervision NAC 70 VRMS with 3 Class A/B Constant Supervision
NACs (Converts 3 on-board NACs to Constant Supervision) (743-164)
• 4100-1266 Expansion Signal Card Expansion NAC Board with 3 Class B NACs
(743-302)
• 4100-1267 Expansion Signal Card Class A Adapter (Converts 3 on-board NACs to
Class A (743-303)
• 4100-1268 Expansion Signal Card Constant Supervision NAC Adapter, 25 or 70 VRMS
with 3 Class A/B Constant Supervision NACs (Converts 3 on-board NACs to Constant
Supervision) (743-304)
• 4100-5116 Expansion Signal Card with 3 Class B NACs (743-159)
Amplifiers Note: The following amplifiers are used only in the 4100U and 4100ES systems, and are not compatible
with the Constant Supervision NAC (CSNAC) option.
100 W Analog Amplifiers:
• 4100-1214 Amp – 120 VAC, 25 VRMS (742-550)
• 4100-1215 Amp – 120 VAC, 70 VRMS (742-551)
• 4100-1216 Amp – 120 VAC, 25 VRMS – Canada (742-552)
• 4100-1217 Amp – 120 VAC, 70 VRMS – Canada (742-553)
• 4100-1218 Amp – 220/230/240 VAC, 25 VRMS (742-554)
• 4100-1219 Amp – 220/230/240 VAC, 70 VRMS (742-555)
• 4100-1220 Backup Amp – 120 VAC, 25 VRMS (742-550)
• 4100-1221 Backup Amp – 120 VAC, 70 VRMS (742-551)
Continued on the next page
