1-17
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Annunciator
Modules
The following annunciator modules are available for the 4100ES.
• 4100-1279 2-inch (51-mm) Blank Display Module (742-519)
• 4100-1280 8-Switch/8-LED Display Card (Red LEDs) (742-509)
• 4100-1281 8-Switch/8-LED Display Card (Yellow LEDs) (742-508)
• 4100-1282 8-Switch/16-LED Display Card (1 red / 1 yellow LED per switch) (742-408)
• 4100-1283 8-Switch/16-LED Display Card (2 yellow LEDs per switch) (742-409)
• 4100-1284 8-Switch/16-LED Display Card (1 red / 1 green LED per switch) (742-407)
• 4100-1285 16-Switch/16-LED Display Card (Red LEDs) (742-507)
• 4100-1286 Hands Off Auto (HOA) Switch Display Card (742-514)
• 4100-1287 24-Switch/24-LED Display Card (Red LEDs) (742-506)
• 4100-1288 LED/Switch Controller Card (742-410)
• 4100-1289 Expansion LED/Switch Controller Card (No mounting plate) (742-626)
• 4100-1290 24-Point Graphic I/O Module (742-726)
• 4100-1291 Remote Unit Interface Card (742-727)
• 4100-1292 Remote Command Center (742-737)
• 4100-1293 Panel-Mounted Printer (742-739)
• 4100-1294 LED/Switch Slide-In Label Kit (for up to 3 Bays) (742-863)
• 4100-1295 HOA Module (No Text) with 24 Switches and 24 Red LEDs (742-874)
Transponders and
Transponder
Components
The following is a list of transponder cabinets and components for the 4100ES.
• 4100-9600 Basic Transponder (Expansion Bay with PDI and Basic TIC) (742-866)
• 4100-9601 Local Mode Transponder (Expansion Bay with PDI and Local Mode TIC)
(742-867)
• 4100-0620 Basic Transponder Interface Card (TIC) (742-520)
• 4100-0621 Analog Audio Riser Module (742-534)
• 4100-0622 Digital Audio Riser Module (742-535)
• 4100-0625 Local Mode TIC (742-521)
• 4100-0632 Terminal Block Utility Module (742-695)
• 4100-0633 Transponder Cabinet Tamper Switch (742-738)
•
4100-1341 MCC Digital Audio Riser Module (743-850)
Audio Operator
Interfaces
The following modules are used only with the 4100U and 4100ES systems.
• 4100-1252 Audio Operator Interface – 1 Channel (742-798)
• 4100-1253 Audio Operator Interface – 1.5 Channel (742-801)
• 4100-1254 Audio Operator Interface – 2 Channel (742-799)
• 4100-1255 Audio Operator Interface – 3-8 Channel (742-800)
Audio Controller
Boards
The following audio controller boards are used with the audio operator interface.
• 4100-1210 Audio Controller Board – Analog, 1.5 Channels (742-517)
• 4100-1211 Audio Controller Board – Digital (742-387)
• 4100-1311 Audio Controller Board – Digital (743-446)
