1-9
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs
Overview This section lists the PIDs (model numbers) that are supported by the 4100ES Fire Alarm
System. There are two basic types of PIDs listed here:
• PIDs denoting standard installations, such as host panels containing multiple, already
functioning modules
• PIDs denoting individual modules or back boxes
- offered as an after-market product for standard installations
- offered as options or aftermarket product for configured installations
The 4100ES features either a 2x40 alphanumeric display, or the multi-line LCD of the Flexible
User Interface.
Note: Software-related PIDs, such as vertical market software packages and programmer options, are not
listed in this manual.
Basic Control
Panels (United
States)
Control panels available in the U.S. that use the SPS:
• 4100-9111 2x40 Master Controller – Domestic (742-830)
4100-9114 Flexible User Interface Master Controller – Domestic (743-201)
(120 VAC 60 HZ), Display, CPU Card, System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger and 9 A Total Signal/Card
Power.
• 4100-9121 2x40 Redundant Master Controller – Domestic (742-729)
(120 VAC 60 HZ), Displays (2), CPU Cards (2), System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger and 9 A Total Signal/Card
Power. Occupies two bays.
• 4100-9122 Flexible User Interface Redundant Master Controller – Domestic (743-239)
(120 VAC 60 HZ), Display, CPU Cards (2), System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger and 9 A Total Signal/Card
Power. Occupies two bays.
• 4100-9131 Master Controller – Domestic (742-844)
(120 VAC 60 HZ), No Display, CPU Card, System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger and 9 A Total Signal/Card
Power.
Control panels available in the U.S. that use the EPS:
• 4100-9311 Master Controller – Domestic (743-1026)
(120VAC 50/60HZ) 2x40 Display, CPU Card, Isolated RUI channel (RUI+), Power
Distribution Interface Board, Power Supply that includes 250 Addressable/Analog Points,
1 Isolated IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC
(127 devices per IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger
(ULC Listed for charging external 50 Ah batteries) and 9A Total Signal/Card Power,
207 Watts Notification Appliance Power (9A @ 23V), 54 Watts field wiring power
(6V drop, 9A), System, IDNet and RUI+ Earth Fault Detection.
Continued on the next page
