Simplex 4100ES Installation Guide

1-24
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100 PIDs (Non-4100ES/4100U) (continued)
Miscellaneous
Modules
• 4100-0133 Tamper Switch
• 4100-1010 External Battery Power and Charger
Network Modules The following modules are intended to be used in a networked 4100 system.
• 4120-6014 Modular Interface Board
• 4120-6023 Physical Bridge (Style 4)
• 4120-6024 Physical Bridge (Style 7)
• 4120-0142 Wired Media Card
• 4120-0143 Fiber-Optic Media Card
• 4120-0144 Modem Media Card
• 4120-0156 8 VDC Module (provides 3 A from 28 V tap)
System
Accessories
• 2080-9047 DACT Communication Cable (14 feet [4 meters]) (733-913)
• 2081-9031 Potted Module for PVCS (740-688)
• 2081-9272 Batteries (6.2 Ah) (112-112)*
• 2081-9274 Batteries (10 Ah) (112-113)*
• 2081-9275 Batteries (18.8 Ah) (112-046)*
• 2081-9276 Batteries (33 Ah) (112-053)*
• 2081-9279 Batteries (110 Ah) (112-123)*
• 2081-9287 Batteries (25 Ah) (112-134)*
• 2081-9288 Batteries (12.7 Ah) (112-133)*
• 2081-9296 Batteries (50 Ah) (112-136)*
• 4190-9803 Replacement Paper for 4100-0451 Panel-Mounted Printer (473-019)
*Or the equivalent.

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
