J-1
Appendix J
Cooper Wheelock Appliances Compatible With 4100ES
Wheelock Protocol For Special Applications
Overview The tables in this appendix list Cooper Wheelock appliances compatible with 4100ES
Wheelock protocol for special applications.
Synchronizing
Horn Strobes
Table J-1. Synchronizing Horn Strobes
Appliance Description
AS-241575W AS Series Horn Strobe. 24VDC, 15/75Cd, Wall Mount
AS-24MCW AS Series Horn Strobe. 24VDC, Multi-Cd, Wall Mount
AS-24MCC AS Series Horn Strobe. 24VDC, Multi-Cd, Ceiling Mount
AS-24MCWH AS Series Horn Strobe. 24VDC, Multi-High-Cd, Wall Mount
AS-24MCCH AS Series Horn Strobe. 24VDC, Multi-High-Cd, Ceiling Mount
ASWP-2475W, ASWP-2475C AS Series WP Horn Strobe. 24VDC, 30Cd, Wall or Ceiling Mount
ASWP-24MCWH AS Series WP Horn Strobe. 24VDC, Multi-High-Cd, Wall Mount
ASWP-24MCCH AS Series WP Horn Strobe. 24VDC, Multi-High-Cd, Ceiling Mount
ASA-24MCW, ASB-24MCW AS Series Horn Strobe. 24VDC, Multi-Cd, Wall Mount. Amber/Blue
ASA-24MCC, ASB-24MCC
AS Series Horn Strobe. 24VDC, Multi-Cd, Ceiling Mount. Amber/Blue
HSR HN STR, Red , 2-Wire, Wall, 12/24VDC, 3dB, 8CD, 5 Mount
HSRC HN STR, Red, 2-wire, Ceiling Mount, 12/24VDC, 3dB, 8 Cd, 5 Mount
HSRCS
HN STR, Silver red, 2-wire, Ceiling Mount, 12/24VDC, 3dB, 8 Cd, 5 Mount
HSRS HN STR, Silver Red, 2-Wire, Wall, 12/24VDC, 3dB, 8CD, 5 Mount
HSW HN STR, White, 2-Wire, Wall, 12/24VDC, 3dB, 8CD, 5 Mount
HSWC
HN STR, White, 2-wire, Ceiling Mount, 12/24VDC, 3dB, 8 Cd, 5 Mount
HSWCS
HN STR, Silver white, 2-wire, Ceiling Mount, 12/24VDC, 3dB, 8 Cd, 5
Mount
HSWS HN STR, Silver White, 2-Wire, Wall, 12/24VDC, 3dB, 8CD, 5 Mount
HS4-241575W HS4 Series Horn Strobe. 24VDC, 15/75Cd, Wall Mount
HS4-24MCW HS4 Series Horn Strobe. 24VDC, Multi-Cd, Wall Mount
HS4-24MCWH HS4 Series Horn Strobe. 24VDC, Multi-High-Cd, Wall Mount
HS4-24MCC HS4 Series Horn Strobe. 24VDC, Multi-Cd, Ceiling Mount
NS-241575W NS Series Horn Strobe. 24VDC, 15/75Cd, Wall Mount
NS-24MCW NS Series Horn Strobe. 24VDC, Multi-Cd, Wall Mount
NS-24MCC NS Series Horn Strobe. 24VDC, Multi-Cd, Ceiling Mount
NS-24MCCH NS Series Horn Strobe. 24VDC, Multi-High-Cd, Ceiling Mount
ZNS-MCW ZNS Series Horn Strobe. 24VDC, Multi-Cd, Wall Mount
ZNS-MCWH ZNS Series Horn Strobe. 24VDC, Multi-High-Cd, Wall Mount
ZNS-24MCC ZNS Series Horn Strobe. 24VDC, Multi-Cd, Ceiling Mount
ZNS-24MCCH ZNS Series Horn Strobe. 24VDC, Multi-High-Cd, Ceiling Mount
