Simplex 4100ES - Audio Options; Annunciation Modules

1-23
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100 PIDs (Non-4100ES/4100U) (continued)
Audio Controllers
and Amplifiers
The following modules can be used in 4100ES Upgrade/Retrofit applications, but cannot be
used with 4100ES audio modules.
• 4100-0210 Single-Channel Audio Controller Board
• 4100-0211 Dual-Channel Audio Controller Board
• 4100-0212 Triple-Channel Audio Controller Board
• 4100-0201 25 VRMS/25 W Audio Amplifier (no Power Supply; Power Limited)
• 4100-0202 25 VRMS/Dual 25 W Audio Amplifier (with Power Supply; Power Limited)
• 4100-1203 25 VRMS/100 W Audio Amplifier (120 VAC; Power Limited)
• 4100-0203 25 VRMS/100 W Audio Amplifier (120 VAC; Non-Power Limited)
• 4100-0213 25 VRMS/100 W Audio Amplifier (240 VAC; Non-Power Limited)
• 4100-0207 70 VRMS/100 W Audio Amplifier (120 VAC; Non-Power Limited)
• 4100-0217 70 VRMS/100 W Audio Amplifier (240 VAC; Non-Power Limited)
• 4100-1207 70 VRMS/90 W Audio Amplifier (120 VAC; Power Limited)
Audio Options The following options can be used in 4100ES Retrofit/Upgrade systems with 4100 Back
Boxes.
• 4100-0204 Microphone and Enclosure
• 4100-0205 Master Telephone
• 4100-0206 Redundant Tone Generator
• 4100-0215 Phone Riser Terminal Block
Annunciation
Modules
• 4100-0301 64/64 LED/Switch Controller
• 4100-0302 24-Point I/O Graphic Interface
• 4100-0401 8-LED Display Card (Red Led)
• 4100-0402 16-Point Display Card (Red/Yellow LEDs)
• 4100-0403 8-Switch/8-LED Display Card (Momentary switches; red LEDs)
• 4100-0404 8-Switch/16-LED Display Card (Maintained switches; one red and one green
LED per switch)
• 4100-0405 8-Switch/16-LED Display Card (Maintained switches; one red and one yellow
LED per switch)
• 4100-0408 8-Switch/8-LED Annunciator Control Switch Module
• 4100-0450 Remote Panel LCD
