Simplex 4100ES Installation Guide

1-8
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES Back Box PIDs
Overview This section lists all back box PIDS for the 4100ES Fire Alarm System.
4100ES Back
Boxes
The 4100ES Back Boxes are shipped as follows:
Box and door enclosures:
2975-9441 One Bay Back Box, Glass Door and Dress Panels – Red (743-934)
2975-9442 Two-Bay Back Box, Glass Door and Dress Panel – Red (743-935)
2975-9443 Three-Bay Back Box, Glass Door and Dress Panel – Red (743-936)
2975-9444 One-Bay Back Box, Glass Door and Dress Panel – Platinum (743-937)
2975-9445 Two-Bay Back Box, Glass Door and Dress Panel – Platinum (743-938)
2975-9446 Three-Bay Back Box, Glass Door and Dress Panel – Platinum (743-939)
2975-9447 One-Bay Back Box, Solid Door and Dress Panel – Red (743-940)
2975-9448 Two-Bay Back Box, Solid Door and Dress Panel – Red (743-941)
2975-9449 Three-Bay Back Box, Solid Door and Dress Panel – Red (743-942)
2975-9450 One-Bay Back Box, Solid Door and Dress Panel – Platinum (743-943)
2975-9451 Two-Bay Back Box, Solid Door and Dress Panel – Platinum (743-944)
2975-9452 Three-Bay Back Box, Solid Door and Dress Panel – Platinum (743-945)
Doors and Dress Panels:
4100-2104 One-Bay Glass Door and Dress Panel - Platinum (743-950)
4100-2105 Two-Bay Glass Door and Dress Panel - Platinum (743-951)
4100-2106 Three-Bay Glass Door and Dress Panel - Platinum (743-952)
4100-2114 One-Bay Solid Door and Dress Panel - Platinum (743-953)
4100-2115 Two-Bay Solid Door and Dress Panel - Platinum (743-954)
4100-2116 Three-Bay Solid Door and Dress Panel - Platinum (743-955)
4100-2124 One-Bay Glass Door and Dress Panel - Red (743-956)
4100-2125 Two-Bay Glass Door and Dress Panel - Red (743-957)
4100-2126 Three-Bay Glass Door and Dress Panel - Red (743-958)
4100-2134 One-Bay Solid Door and Dress Panel - Red (743-959)
4100-2135 Two-Bay Solid Door and Dress Panel - Red (743-960)
4100-2136 Three-Bay Solid Door and Dress Panel - Red (743-961)
Back Boxes by themselves:
2975-9407 One-Bay Red Box (742-414)
2975-9408 Two-Bay Red Box (742-416)
2975-9409 Three-Bay Red Box (742-418)
2975-9438 One-Bay Back Box - Platinum (743-946)
2975-9439 Two-Bay Back Box - Platinum (743-947)
2975-9440 Three-Bay Back Box - Platinum (743-948)
Accessories:
2975-9812 Red Trim Band (742-638)
2975-9813 Semi-Flush Trim Band – Platinum (743-949)

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
