1-10
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Basic Control
Panels (United
States)
• 4100-9314 Master Controller – Domestic (743-1027)
(120VAC 50/60HZ) InfoAlarm (English) Display with raised keys, CPU Card, Isolated
RUI channel, Power Distribution Interface Board, Power Supply that includes 250
Addressable/Analog Points, 1 Isolated IDNet channel, 189 Addressable TrueAlert Points,
3 Class B IDNAC (127 devices per IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah
Battery Charger (ULC Listed for charging external 50 Ah batteries) and 9A Total Signal/
Card Power, 207 Watts Notification Appliance Power (9A @ 23V), 54 Watts field wiring
power (6V drop, 9A), System, IDNet and RUI+ Earth Fault Detection.
• 4100-9331 Master Controller– Domestic (743-1028)
(120VAC 50/60HZ) No Display, CPU Card, Isolated RUI channel, Power Distribution
Interface Board, Power Supply that includes 250 Addressable/Analog Points, 1 Isolated
IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127 devices per
IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC Listed for
charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection.
Basic Control
Panels(Canada)
Control panels available in Canada that use the SPS:
• 4100-9112 2x40 Master Controller – Canadian English (742-831)/
4100-9115 Flexible User Interface Master Controller – Canadian English (743-202)
(120 VAC 60 HZ), Display, CPU Card, System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, Battery Cutout Circuit,
and 9 A Total Signal/Card Power.
• 4100-9113 2x40 Redundant Master Controller – Canadian French (742-832)/
4100-9116 Flexible User Interface Redundant Master Controller –
Canadian French (743-203)
(120 VAC 60 HZ), Display, CPU Card, System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, Battery Cutout Circuit,
and 9 A Total Signal/Card Power.
• 4100-9132 Master Controller – Canadian English (742-845)
(120 VAC 60 HZ), No Display, CPU Card, System Power Supply that includes 250
Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux. Relay, 24
VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, Battery Cutout Circuit, and 9 A
Total Signal/Card Power.
• 4100-9133 Master Controller – Canadian French (742-846)
(120 VAC 60 HZ), No Display, CPU Card, System Power Supply that includes 250
Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux. Relay, 24
VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, Battery Cutout Circuit, and 9 A
Total Signal/Card Power.
