Simplex 4100ES Installation Guide

1-11
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Basic Control
Panels (Canada)
Control panels available in Canada that use the EPS:
• 4100-9312 Master Controller – Canadian English (743-1029)
(120VAC 50/60HZ) 2x40 Display, CPU Card, Isolated RUI channel, Power Distribution
Interface Board, Power Supply that includes 250 Addressable/Analog Points, 1 Isolated
IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127 devices per
IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC Listed for
charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts 
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection.
• 4100-9313 Master Controller – Canadian French (743-1030)
(120VAC 50/60HZ) 2x40 Display, CPU Card, Isolated RUI channel, Power Distribution
Interface Board, Power Supply that includes 250 Addressable/Analog Points, 1 Isolated
IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127 devices per
IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC Listed for
charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts 
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection.
• 4100-9315 Master Controller – Canadian English (743-1031)
(120VAC 50/60HZ) InfoAlarm Display, CPU Card, Isolated RUI channel, Power 
Distribution Interface Board, Power Supply that includes 250 Addressable/Analog Points,
1 Isolated IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127
devices per IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC
Listed for charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection.
• 4100-9316 Master Controller – Canadian French (743-1032)
(120VAC 50/60HZ) InfoAlarm Display, CPU Card, Isolated RUI channel, Power 
Distribution Interface Board, Power Distribution Interface Board, Power Supply that
includes 250 Addressable/Analog Points, 1 Isolated IDNet channel, 189 Addressable
TrueAlert Points, 3 Class B IDNAC (127 devices per IDNAC), 24VAux. Power Tap/
Simple NAC, 115 Ah Battery Charger (ULC Listed for charging external 50 Ah batteries)
and 9A Total Signal/Card Power, 207 Watts Notification Appliance Power (9A @ 23V),
54 Watts field wiring power (6V drop, 9A), System, IDNet and RUI+ Earth Fault
Detection.
• 4100-9332 Master Controller – Canadian English (743-1033)
(120VAC 50/60HZ) No Display, CPU Card, Isolated RUI channel, Power Distribution
Interface Board, Power Supply that includes 250 Addressable/Analog Points, 1 Isolated
IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127 devices per
IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC Listed for
charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts 
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection.

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
