Chapter 1 Introduction to the 4100ES Fire Alarm System
4100 PIDs (non-4100ES/4100U)
Overview This section lists the 4100, non-4100ES/4100U, PIDs that are supported by the 4100ES Fire
Alarm System (in retrofit applications). There are two basic types of PIDs listed here:
• PIDs denoting standard installations, such as host panels containing multiple, already
functioning modules
• PIDs denoting individual modules or back boxes:
- offered as after-market product for standard installations
- offered as options or aftermarket product for configured installations
Note: Software-related PIDs, such as vertical market software packages and programmer options, are not
listed in this book.
System Types
and Options
There are six standard types of 4100 control panels used with the 4100. A PID identifies each
system type. These PIDs are combined with the more specific PIDs listed after this topic to
meet the requirements of custom installations:
• 4100-8001 Fire Alarm Control Panel
• 4100-8002 Remote Annunciator Panel
• 4100-8010 MINIPLEX Fire Alarm Control Panel
• 4100-8019 MINIPLEX Fire Alarm Control Panel with Transponder
• 4100-8201 Fire Alarm Control Panel with Audio
• 4100-8210 MINIPLEX Fire Alarm Control Panel with Audio
• 4100-8901/8909 Add-On to Existing System or Annunciator
• 4100-6050/6051 Power Limited Panel/Non-Power Limited Panel
Master Controller
Option Module
4100-6001 240 VAC Controller Power Input
