Simplex 4100ES Installation Guide

1-20
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Amplifiers 100 W Digital Amplifiers:
• 4100-1328 Amp – 120 VAC, 25 VRMS (743-449)
• 4100-1329 Amp – 120 VAC, 70 VRMS (743-450)
• 4100-1330 Amp – 120 VAC, 25 VRMS – Canada (743-451)
• 4100-1331 Amp – 120 VAC, 70 VRMS – Canada (743-452)
• 4100-1332 Amp – 220/230/240 VAC, 25 VRMS (743-453)
• 4100-1333 Amp – 220/230/240 VAC, 70 VRMS (743-454)
• 4100-1334 Backup Amp – 120 VAC, 25 VRMS (743-449)
• 4100-1335 Backup Amp – 120 VAC, 70 VRMS (743-450)
• 4100-1336 Backup Amp – 120 VAC, 25 VRMS – Canada (743-451)
• 4100-1337 Backup Amp – 120 VAC, 70 VRMS – Canada (743-452)
• 4100-1338 Backup Amp – 220/230/240 VAC, 25 VRMS (743-453)
• 4100-1339 Backup Amp – 220/230/240 VAC, 70 VRMS (743-454)
Analog Flex Amplifiers:
• 4100-1312 Analog Flex 50 W Amp – 25 VRMS (743-436)
• 4100-1313 Analog Flex 50 W Amp – 70 VRMS (743-437)
• 4100-1361 Analog Flex 35 W Amp – 25 VRMS (743-444)
• 4100-1362 Analog Flex 35 W Amp – 70 VRMS (743-445)
Digital Flex Amplifiers:
• 4100-1326 Digital Flex 50 W Amp – 25 VRMS (743-447)
• 4100-1327 Digital Flex 50 W Amp – 70 VRMS (743-448)
• 4100-1363 Digital Flex 35 W Amp – 25 VRMS (743-455)
• 4100-1364 Digital Flex 35 W Amp – 70 VRMS (743-456)
Miscellaneous
Modules
The following modules are for 4100ES systems:
• 4100-0650 Battery Shelf (for 50 Ah batteries) (742-840)
• 4100-0640 Memory Add-On Module for Flexible User Interface (743-279)
• 4100-5128 Battery Distribution Terminal Module (742-843)
• 4100-9854 4100U/4100ES Module Legacy Bay Mounting Kit (743-856)

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
