Simplex 4100ES Installation Guide

1-16
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Communication
Modules
• 4100-6065 BMUX Communication Module (743-645)
• 4100-6069 BACpac Ethernet (743-747)
• 4100-6080 DACT Side Mounted (743-1041)
Power Supplies The power supplies listed below can be used with 4100ES systems.
• 4100-5101 Expansion Power Supply (XPS) (120 VAC) (60 Hz) (742-383)
• 4100-5102 Expansion Power Supply (XPS) (220/230/240 VAC) (50/60 Hz) (742-384)
• 4100-5103 Expansion Power Supply (XPS) (120 VAC) (60 Hz) (Canada) (742-385)
• 4100-5111 System Power Supply (SPS) (120 VAC) (60 Hz) (742-631)
• 4100-5112 System Power Supply (SPS) (220/230/240 VAC) (50/60 Hz) (742-632)
• 4100-5113 System Power Supply (SPS) (120 VAC) (60 Hz) (Canada) (742-633)
• 4100-5115 Expansion NAC Module (XNAC) (742-386)
• 4100-5120 TrueAlert Power Supply (TPS) (120 VAC) (742-659)
• 4100-5121 TrueAlert Power Supply (TPS) (120 VAC) (Canada) (742-660)
• 4100-5122 TrueAlert Power Supply (TPS) (220/230/240 VAC) (742-661)
• 4100-5124 TrueAlert Class A Adapter Module (742-662)
• 4100-5125 Remote Power Supply (RPS) (120 VAC) (742-628)
• 4100-5126 Remote Power Supply (RPS) (120 VAC) (Canada) (742-629)
• 4100-5127 Remote Power Supply (RPS) (220/230/240 VAC) (742-300)
• 4100-5152 12 V, 2 A Power Option (742-718)
• 4100-5153 13 A Utility Power Supply (24 VDC/120 VAC) (2120) (742-719)
• 4100-5154 13 A Utility Power Supply (24 VDC/240 VAC) (2120) (742-720)
• 4100-5155 8 A Expansion Power Supply with 4 A Charger 120/240 VAC (2120) (742-517)
• 4100-0156 8 VDC Converter (742-816)
• 4100-5311 120 V 50/60 Hz EPS with IDNet 2 Card
• 4100-5313 220/230/240 V 50/60 Hz EPS with IDNet 2 Card
• 4100-5325 120 V 50/60 Hz EPS
• 4100-5327 220/230/240 V 50/60Hz EPS
Signaling
Modules
The signaling modules listed below can be used with 4100ES systems.
• 4100-5005 8-Zone Module (Class B) (742-655)
• 4100-5015 8-Zone Module (Class A) (742-721)
• 4100-3201 4-Relay Module (2 A) (742-722)
• 4100-3202 4-Relay Module (10 A) (742-723)
• 4100-3203 8-Relay Module (3 A) (742-724)
• 4100-3204 4-Point Relay Module (2 A) (742-948)
• 4100-3206 8-Point Relay Module (3 A) (742-949)

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
