1-14
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Remote Display
Assemblies
• 4100-9401 Red Flexible User Interface Remote Display Assembly - Domestic
(743-187). Includes a remote box with a Flexible User Interface display and a TIC
(566-692).
• 4100-9402 Beige Flexible User Interface Remote Display Assembly - Domestic
(743-188). Includes a remote box with a Flexible User Interface display and a TIC (566-692).
• 4100-9421 Red Flexible User Interface Remote Display Assembly – Canadian French
(743-189). Includes a remote box with a Flexible User Interface display and a TIC (566-692).
• 4100-9422 Beige Flexible User Interface Remote Display Assembly – Canadian French
(743-190). Includes a remote box with a Flexible User Interface display and a TIC
(566-692).
• 4100-9441 Red Flexible User Interface Remote Display Assembly – International
(743-191). Includes a remote box with a Flexible User Interface display and a TIC (566-692).
• 4100-9442 Beige Flexible User Interface Remote Display Assembly – International
(743-192). Includes a remote box with a Flexible User Interface display and a TIC (566-692).
Basic Audio
Selections
This section lists the two audio cabinets, both of which include an audio expansion bay with a
power distribution interface (PDI), audio controller board, and a microphone module.
• 4100-9620 Basic Audio with Microphone – Analog (742-869)
• 4100-9601 Basic Audio with Microphone – Digital (742-870)
Note: Refer to Appendix K for information about 520 Hz compatible audio components.
Utility Cabinets This section lists the two utility cabinets, which contain mounting rails for bays and mounting
plates for 2120 modules.
• 4100-9642 Two-Bay Utility Cabinet Kit (for 2120 Equipment) (742-871). Includes
two-bay mounting rails and two 4100 (non-4100ES/4100U) expansion bays.
• 4100-9643 Three-Bay Utility Cabinet Kit (for 2120 Equipment) (742-872). Includes
three-bay mounting rails and three 4100 (non-4100ES/4100U) expansion bays.
Note: The rack-mount option is not Listed for security applications and cannot be used to
provide monitoring of security parts.
Master Controller
Upgrade Kits
Upgrade kits are used for retrofitting newer modules into old-style systems.
• 4100-7150 Master Controller Upgrade with 2x40 Display (old 4100 to Rev 10 or higher)
(742-592)
• 4100-7151 Master Controller Upgrade with No Display (old 4100 to Rev 10 or higher)
(742-394)
• 4100-7152 Master Controller Upgrade with 2X40 Display, operator interface and power
supply (old 4100 to Rev 10 or higher) (742-922)
• 4100-7153 Flexible User Interface Display Upgrade (4100ES with 2x40 display to
Flexible User Interface display) (743-240)
• 4100-7154 Master Controller Upgrade with Flexible User Interface Display (old 4100 to
Rev 10 or higher) (743-241)
• 4100-7158 NXP Master Controller Upgrade w/o Display (Legacy 4100 to Rev 13 or
higher) (743-777
• 4100-9833 Master Controller Upgrade with 2x40 Display in One-Bay Beige Enclosure
(4020) (742-804)
Note: The rack-mount option is not Listed for security applications and cannot be used to
provide monitoring of security parts.
