Simplex 4100ES Installation Guide

iii
Listings, Approvals, Codes, and Standards
Listings and
Approvals
This equipment meets the requirements of the following agencies.
• UL (UL 864)
• ULC (S527)
• FM (Class No. 3010)
• CSFM
• MEA
Codes and
Standards
If the notification appliances and accessories referenced in Table I are installed in accordance
with either NFPA 12A or NFPA 2001, the system must employ an additional mechanically-
operated manual release mechanism.
The installer should be familiar with the relevant codes listed below, as well as any other
applicable local codes and standards, when installing a fire alarm system.
NFPA 72 National Fire Alarm and Signaling Code
NFPA 11 Standard for Low-Expansion Foam and Combined Agent Systems
NFPA 11A Standard for Medium- and High-Expansion Foam Systems
NFPA 12 Standard for Carbon Dioxide Extinguishing Systems
NFPA 12A Standard on Halon 1301 Fire Extinguishing Systems
NFPA 13 Standard for Installation of Sprinkler Systems
NFPA 14 Standard for the Installation of Standpipe and Hose Systems
NFPA 15 Standard for Water Spray Fixed Systems for Fire Protection
NFPA 16 Standard for the Installation of Deluge Foam-Water Sprinkler and Foam-
Water Spray Systems
NFPA 16A Standard for the Installation of Closed-Head Foam-Water Sprinkler Systems
NFPA 17 Standard for Dry Chemical Extinguishing Systems
NFPA 17A Standard for Wet Chemical Extinguishing Systems
NFPA 25 Standard for Inspection, Testing, and Maintenance of Water-Based Fire
Protection Systems
NFPA 70 National Electric Code
NFPA 72 National Fire Alarm and Signaling Code
NFPA 101 Life Safety Code
NFPA 750 Standard on Water Mist Fire Protection Systems
NFPA 2001 Standard on Clean Agent Fire Protection Systems
ULC S524 Standard for Installation of Fire Alarm Systems (Canadian Systems)
UL 1076 Standard for Safety for Proprietary Burglar Alarm Units and Systems
Environmental
Operating Range
The 4100ES and all modules are rated to operate at ambient temperatures from 32
o
F - 120
o
F
(0
o
C - 49
o
C).
The 4100ES and all modules are rated for operation at 90
o
F (32
o
C), 93% RH 
(non-condensing).

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
