3-7
Chapter 3 Installing 4100ES MINIPLEX Components
MINIPLEX System Guidelines
Overview The rules on this page apply exclusively to MINIPLEX systems. Review each guideline before
installing a MINIPLEX 4100ES system.
Guidelines All wiring is 18 AWG (minimum) and 12 AWG (maximum).
All wiring is supervised and power-limited.
All wiring that leaves the building requires overvoltage protection. Install module inside
an UL-Listed electrical box wherever wire enters or exits the building. A maximum of four
2081-9044 Modules may be connected to one channel. The 2081-9044 is rated for 200 mA
(maximum).
For Style 4 operation:
- The maximum distance to any device is 2,500 feet (762 m).
- “T” taps are allowed.
- The total maximum cable load (including all “T” taps) is 10,000 feet (3,048 m).
- Maximum allowed line-to-line capacitance (“+” to “-” terminals) is 0.58 uF. For
applications with shielded wire, be sure that the total capacitance from line to line plus
the shield to either line is no more than 0.58 uF.
For Style 6 or Style 7 operation, the maximum loop distance is 2,500 feet (762 m). “T”
taps are not allowed.
RUI comms are wired to remote cabinets from the CPU motherboard to one of the
following transponder interface cards: 4100-0620 or 4100-0625.
Annunciators and transponder interface cards support Style 7 operation when the system is
wired Class A.
The master control panel must be a 4100ES Fire Alarm Control Panel.
The Style 4 RUI card supports MINIPLEX transponders and 4602/4603 serial
annunciators on the same signaling line circuit.
Up to 4 RUI cards in the 4100ES Control Panel can be used for distributing transponder
wiring in different directions or for supporting different wiring requirements (such as
using a Style 7 RUI for serial annunciators).
Up to 31 transponders can be controlled from the 4100ES Control Panel, and can be
distributed as required among the RUI cards.
A maximum of 30 RUI devices between each TIC is supported.
Note: Old legacy, basic, and local mode TICs have been replaced due to component obsolescence. The
replacement boards listed below are functionally equivalent to the legacy boards.
Table 3-1
Name Legacy Card New Card
Basic Transponder Interface Card 0566-093 0566-1166
Local Transponder Interface Card 0566-094 0566-1167
