Simplex 4100ES Installation Guide

1-19
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Amplifiers • 4100-1222 Backup Amp – 120 VAC, 25 VRMS – Canada (742-552)
• 4100-1223 Backup Amp – 120 VAC, 70 VRMS – Canada (742-553)
• 4100-1224 Backup Amp – 220/230/240 VAC, 25 VRMS (742-554)
• 4100-1225 Backup Amp – 220/230/240 VAC, 70 VRMS (742-555)
100 W Digital Amplifiers (except for 4100-1230 and -1236 [95 W]):
• 4100-1228 Amp – 120 VAC, 25 VRMS (742-544)
• 4100-1229 Amp – 120 VAC, 70 VRMS (742-545)
• 4100-1230 Amp – 120 VAC, 25 VRMS – Canada (742-546)
• 4100-1231 Amp – 120 VAC, 70 VRMS – Canada (742-547)
• 4100-1232 Amp – 220/230/240 VAC, 25 VRMS (742-548)
• 4100-1233 Amp – 220/230/240 VAC, 70 VRMS (742-549)
• 4100-1234 Backup Amp – 120 VAC, 25 VRMS (742-544)
• 4100-1235 Backup Amp – 120 VAC, 70 VRMS (742-545)
• 4100-1236 Backup Amp – 120 VAC, 25 VRMS – Canada (742-546)
• 4100-1237 Backup Amp – 120 VAC, 70 VRMS – Canada (742-547)
• 4100-1238 Backup Amp – 220/230/240 VAC, 25 VRMS (742-548)
• 4100-1239 Backup Amp – 220/230/240 VAC, 70 VRMS (742-549)
Analog Flex Amplifiers:
• 4100-1212 Analog Flex 50 W Amp – 25 VRMS (742-794)
• 4100-1213 Analog Flex 50 W Amp – 70 VRMS (742-795)
• 4100-1261 Analog Flex 35 W Amp – 25 VRMS (743-001)
• 4100-1262 Analog Flex 35 W Amp – 70 VRMS (742-002)
Digital Flex Amplifiers:
• 4100-1226 Digital Flex 50 W Amp – 25 VRMS (742-796)
• 4100-1227 Digital Flex 50 W Amp – 70 VRMS (742-797)
• 4100-1263 Digital Flex 35 W Amp – 25 VRMS (743-003)
• 4100-1264 Digital Flex 35 W Amp – 70 VRMS (743-004)
Note: The following amplifiers are only used in the 4100U and 4100ES systems, and are compatible with
the Constant Supervision NAC (CSNAC) option and 4100U Master Firmware Revision 11.08 or later.
100 W Analog Amplifiers:
• 4100-1314 Amp – 120 VAC, 25 VRMS (743-438)
• 4100-1315 Amp – 120 VAC, 70 VRMS (743-439)
• 4100-1316 Amp – 120 VAC, 25 VRMS – Canada (743-440)
• 4100-1317 Amp – 120 VAC, 70 VRMS – Canada (743-441)
• 4100-1318 Amp – 220/230/240 VAC, 25 VRMS (743-442)
• 4100-1319 Amp – 220/230/240 VAC, 70 VRMS (743-443)
• 4100-1320 Backup Amp – 120 VAC, 25 VRMS (743-438)
• 4100-1321 Backup Amp – 120 VAC, 70 VRMS (743-439)
• 4100-1322 Backup Amp – 120 VAC, 25 VRMS – Canada (743-440)
• 4100-1323 Backup Amp – 120 VAC, 70 VRMS – Canada (743-441)
• 4100-1324 Backup Amp – 220/230/240 VAC, 25 VRMS (743-442)
• 4100-1325 Backup Amp – 220/230/240 VAC, 70 VRMS (743-443)
Continued on the next page

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
