1-12
Chapter 1 Introduction to the 4100ES Fire Alarm System
4100ES PIDs (continued)
Basic Control
Panels
(International)
International control panels that use the SPS:
• 4100-9211 2x40 Master Controller – International (742-848)/
4100-9212 Master Controller – 220/240 V (743-204)
4100-9214 Master Controller – China 220/240V (743-765) (220/230/240 VAC 50/60 HZ),
Display, CPU Card, System Power Supply that includes 250 Addressable/Analog Points, 3
Class A/B NACs, 1 IDNet channel, 24 VDC Aux. Relay,
24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, and 9 A Total Signal/Card Power.
• 4100-9213 Flexible User Interface Master Controller – 220/240 V (743-333)
(120 VAC 60 HZ) Display, CPU Card, System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 V Aux. Relay,
24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, and 9 A Total Signal/Card Power
• 4100-9230 Master Controller – International (742-849)
(220/230/240 VAC 50/60 HZ), No Display, CPU Card, System Power Supply that includes
250 Addressable/Analog Points, 3 Class A/B NACs, 1 IDNet channel, 24 VDC Aux.
Relay, 24 VDC Aux. Power Tap, 50 Ah (Max) Battery Charger, and 9 A Total Signal/Card
Power.
International control panels that use the EPS:
• 4100-9511 Master Controller – International (743-1034)
(220/230/240VAC 50/60HZ) 2x40 Display, CPU Card, Isolated RUI channel, Power
Distribution Interface Board, Power Supply that includes 250 Addressable/Analog Points,
1 Isolated IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127
devices per IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC
Listed for charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection.
• 4100-9512 Master Controller – International (743-1035)
(220/230/240VAC 50/60HZ) InfoAlarm Display (with Slide-in Labels for Language
Customization), CPU Card, Isolated RUI channel, Power Distribution Interface Board,
Power Supply that includes 250 Addressable/Analog Points, 1 Isolated IDNet channel,
189 Addressable TrueAlert Points, 3 Class B IDNAC (127 devices per IDNAC), 24VAux.
Power Tap/Simple NAC, 115 Ah Battery Charger (ULC Listed for charging external 50
Ah batteries) and 9A Total Signal/Card Power, 207 Watts Notification Appliance Power
(9A @ 23V), 54 Watts field wiring power (6V drop, 9A), System, IDNet and RUI+ Earth
Fault Detection.
• 4100-9513 Master Controller – International (743-1036)
(120VAC 50/60HZ) InfoAlarm Display (with Slide-in Labels for Language
Customization), CPU Card, Isolated RUI channel, Power Distribution Interface Board,
Power Supply that includes 250 Addressable/Analog Points, 1 Isolated IDNet channel,
189 Addressable TrueAlert Points, 3 Class B IDNAC (127 devices per IDNAC), 24VAux.
Power Tap/Simple NAC, 115 Ah Battery Charger (ULC Listed for charging external 50
Ah batteries) and 9A Total Signal/Card Power, 207 Watts Notification Appliance Power
(9A @ 23V), 54 Watts field wiring power (6V drop, 9A), System, IDNet and RUI+ Earth
Fault Detection.
• 4100-9531 Master Controller 250PTS (1 Loop) – International (743-1037)
(220/230/240VAC 50/60HZ) 2 X 40 Display, CPU Card, Isolated RUI channel, Power
Distribution Interface Board, Power Supply that includes 250 Addressable/Analog Points,
1 Isolated IDNet channel, 189 Addressable TrueAlert Points, 3 Class B IDNAC (127
devices per IDNAC), 24VAux. Power Tap/Simple NAC, 115 Ah Battery Charger (ULC
Listed for charging external 50 Ah batteries) and 9A Total Signal/Card Power, 207 Watts
Notification Appliance Power (9A @ 23V), 54 Watts field wiring power (6V drop, 9A),
System, IDNet and RUI+ Earth Fault Detection, Power Distribution Module.
