Charts ECDIS-E User Guide
4-78 65934012
Color Diagram
The color diagram ensures that any adjustments made to the brightness
and contrast settings on the monitor will enable the SENC data, such as
coastlines, safety contour and other objects to be adequately displayed. To
access, click on the Color Diagram button.
For a description and additional access to the color diagram, see ‘Chart
Symbols’ in Chapter 12 Brilliance.
