Overview ECDIS-E User Guide
1-2 65934012
ECDIS-E Features
The following table lists all the ECDIS-E product type features.
Feature Additional details
Display controls
Picture brilliance (day/night selection).
Brightness check
Displaying/hiding heading line and synthetics.
Centring and off-centring (MAX view) the picture.
Display of primary, or primary and secondary
presentation displays (vertical/horizontal split
screen or popup window secondary display).
Hides all windows currently shown on the display,
or restore all previously opened windows.
Zoom window defines a specific area of the chart
display to zoom into.
Display Features
A north arrow pointed true north in the upper left
corner of the chart window.
Scale and latitude bars drawn vertically 2 to 4 mm
from the left border of the display.
Defining and displaying
user specified data
Own ship’s position.
Waypoint data.
Wind and depth data.
Scale selection Scale ratio from 1:500 to 1:20,000,000
Range Rings
Range rings on or off. Ring interval dependant on
scale.
Ship’s heading and speed
display
Compass alignment.
Selection of speed mode (through water or over
ground).
Selection of water or ground stabilisation
Selection of Sensor Source
Selection of sensor source for data type (heading,
STW , position etc.)
Selection of presentation
mode
North-up or Course-up
Motion Mode True Motion (TM) only
