Charts ECDIS-E User Guide
4-24 65934012
Chart Settings
The Chart Settings sub menu includes two tab folders:
Layers
Symbology
The Layers folder enables you to display a Standard display mode, with all
standard settings selected, or to select and deselect chart settings for the
currently selected mode.
The Symbology folder enables you to customise display settings for all
chart databases and display settings for specific charts (e.g. C-MAP or
SevenCs databases) from a list of available settings.
CAUTION:
The selection of chart sets and custom features only applies to
vector format charts. Chart settings do not change the display of
raster format (ARCS) charts.
The currently selected chart display mode (i.e. `Standard Chart Display')
is shown as a permanent prompt, see Prompts.
In addition to the access options described in Chart Facility,
the Settings sub-menu can be quickly accessed by right
clicking on the STD button in the lower popup toolbar.
